Specifications
Brand Name :
Lebron-Machinery
Model Number :
C80-300
Certification :
ISO9001: 2008
Place of Origin :
Wuxi, Jiangsu
MOQ :
1 Set
Price :
USD30000 per Set
Payment Terms :
L/C, T/T
Supply Ability :
30 Sets per Month
Delivery Time :
45 days
Packaging Details :
Standard export packing with each machine fixed and protected in the container
Main Power :
11KW
Speed :
Approx 18m/min
Roller Station :
19 stations
Roller Material :
GCr15 bearing steel
Roller Shaft :
No.45 steel. Quenched
Diameter :
75mm
Description

C80-300 C Purlin Roll Forming Machine C Z Purlin Roll Forming Machine Full Automatic

1. Description of C purlin roll forming machine

C purlin roll forming machine is an equipment that produces C shaped steel channels continuously out of galvanized or cold rolled steel strips from feeding, punching for holes, bending and cutting.

The main components of a c sectional channel roll forming machine include a manual de-coiler (3TONs capacity), a feeding guide for materials of different sizes, a leveling device, a front hydraulic punching for holes or slots on flanges, roll forming part, a rear hydraulic punching for holes or slots on web, a hydraulic cutting for cut to length, a PLC control cabinet, and and a hydraulic oil pump.

2. Technical Parameters of C purlin roll forming machine

No. Item Description
1 Raw material width Below 600mm
2 Roll forming speed 15-20m/min
3 Raw material thickness 1.0-3.0mm
4 Type Galvanized Strip
5 Main power 7.5Kw*2
8 Pre-Punch 1 station
9 Main roller stations 16 steps
10 Roller material Gcr15, quenching and tempering
11 Main roller material 45# steel, quenching and tempering, Diameter: 85mm
12 Length Tolerance ±1.5mm
13 Material of cutting Cr12Mov, quench HRC 58-62℃
14 Frequency inverte Panasonic PLC
15 Control system PLC controlling length, encoder is OMRON brand
16 Transmission typ 1.5 single row chain drive
17 Dimension (L*W*H) 8.5m*1.2m*1.2m
18 Voltage 380V,50Hz, 3 phase

3. Main components of C purlin roll forming machine

No. Name Qty
1 Decoiler 1 Set
2 Guider device 1 Set
3 Roll forming unit 1 Set
4 Cutting System 1 Set
5 Punching device 1 Set
6 Output Table 1 Set
7 Control System(PLC) 1 Set
8 Hydraulic station 1 Set

4. C Purlin Sizes

No. D(mm) B(mm) L(mm) T(mm) Coil width (mm)
1 100 50 15 1-3 210
2 120 50 20 1-3 240
3 140 50 20 1-3 260
4 140 60 20 1-3 280
5 150 50 20 1-3 270
6 160 60 20 1-3 300
7 180 60 20 1-3 320
8 180 70 20 1-3 340
9 200 65 20 1-3 350
10 200 70 20 1-3 360
11 220 70 20 1-3 380
12 220 80 20 1-3 400
13 240 70 20 1-3 400
14 240 80 20 1-3 420
15 250 80 20 1-3 430
16 300 70 20 1-3 460
17 300 80 20 1-3 480

5. Application:

The c purlin which was produced by C purlin roll forming machine can be used for the major stress structure of the large and middle-sized industrial constructions and civilian constructions. The roof load bearing and wall panel supporting the plants, warehouses, engine houses, hangars, exhibition halls, cinemas, gymnasiums, fair flower stands, etc.
