Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump
Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump
Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump
Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump
Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump
Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump
Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump
Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump
Specifications
Brand Name :
APK
Model Number :
WQS
Certification :
ISO;CE,BV; TUV; CCC
Place of Origin :
Henan China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
9863 sets per month
Delivery Time :
Within 2-5 working days upon receipt of payment
Packaging Details :
Submersible sewage pump is packed by wooden case or as your request.
Flow Rate :
15-300m3/h
Head :
7-100m
Power :
3-63kw
Install :
Vertical
Motor :
100% Copper Wire
Voltage :
380v or customized
Material :
Cast iron or customized
Outlet diameter :
φ25~φ200mm
Description

WQS Cast Iron Water Filled Capacity15-300m3/h Wastewater Submersible Sewage Pump

WQS submersible sewage pump overview:

WQS series sewage pump is non-clogging sewage pump which is ssuccessfully developed basing on the introduction of advanced technology from abroad. By far, it is the most advanced sewage disposal equipment in China. It saves much energy, prevents clogging and winding. Large solid particles can pass through it easiliy. It features automatic installation and detection, etc

  • Type: WQ series sewage pump
  • Power: 5.5kw-37kw
  • Frequency: 3 phase 50hz/60hz
  • Flow: 15-300m3/h
  • Head: 7-100m
  • Material: Cast iron

WQS submersible sewage pump applications:

  • Sewage water contains solid particles, long fiber
  • Municipal and industrial waste water
  • Sewage treatment
  • Construction

WQS submersible sewage pump overview:

Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump

Electric Submersible Sewage Pump 15-300m3/H , Continuous Use Dirty Water Pump

WQS submersible sewage pump parameters:

Model

Capacity

(m3/h)

Head

(m)

Power

(kw)

WQS15-40/1

15

40

5.5

WQS30-20/1

30

20

5.5

WQS15-50/1

15

50

7.5

WQS30-35

30

35

7.5

WQS15-60/1

15

60

9.2

WQS140-10/1

140

10

9.2

WQS15-80/1

15

80

11

WQS150-10

150

11

11

WQS100-20/1

100

20

13

WQS200-12/1

200

12

15

WQS180-15/1

180

15

15

WQS300-10/1

300

10

18.5

WQS200-16/1

200

16

18.5

WQS50-80/1

50

80

22

WQS300-12/1

300

12

22

WQS200-20/1

200

20

25

WQS100-50/1

100

50

25

WQS300-16/1

300

16

30

WQS100-60/1

100

60

30

WQS200-30/1

200

30

30

WQS100-60/1

100

60

30

WQS200-40

200

40

37

WQS300-25/1

300

25

37

If these submersible sewage pump do not meet your demand, please feel free to contact us. We will choose one suitable model for you.

WQS submersible sewage pump using condition:

  1. Voltage 380V or 660V (allowance error: 5%), 50Hz, three-phase alternating-current supply
  2. solid material volume ratio in pumped medium should be below 2%, Maximum pumped medium density is 1.2*103kg/ m3
  3. PH value should be 4-12
  4. Temperature should be not less than 50℃
