10 Hp 10kw Borehole Stainless Steel Submersible Well Pump AC 3 Phase 50hz / 60hz Frequency
10 Hp 10kw Borehole Stainless Steel Submersible Well Pump AC 3 Phase 50hz / 60hz Frequency
10 Hp 10kw Borehole Stainless Steel Submersible Well Pump AC 3 Phase 50hz / 60hz Frequency
10 Hp 10kw Borehole Stainless Steel Submersible Well Pump AC 3 Phase 50hz / 60hz Frequency
Specifications
Brand Name :
APK
Model Number :
water submersible pump
Certification :
CE; ISO9001; Five stars after-sale service
Place of Origin :
Henan, China
MOQ :
1 piece
Price :
please kindly contact
Payment Terms :
T/T , Western Union , L/C , D/A , D/P , MoneyGram
Supply Ability :
10000 Unit/Units per Month
Delivery Time :
7-15 working days after payment confirmed
Packaging Details :
submersible water pump with Shock absorption,moisture-proof package, standard export wooden case
Power :
7.5kw 10kw submersible pump
Outlet size :
1.2" 2" 3" 4"
Diameter :
7 8 10 inch submersible pump
Capacity :
9-120m3/h
Head :
12m-140m
Frequency :
AC 3 Phase 50hz/60hz
Voltage :
380v/440v/480v/600v/660v or as per request
Material :
cast iron/SS304/SS316/SS316L/Duplex stainless/SS904L
Warranty :
24 months
Description

20m3/h 32m3/h 40m3/h 50m3/h 10 hp 10kw water borehole deep well submersible pump

10hp 10kw water submersible pump performance range:

1. Diameter: 7 8 10 inch submersible pump
2. Flow: 9m3/h-120m3/h
3. Head: 12m-140m
4. Power: 7.5kw 10kw (10hp 14hp)
5. Voltage: 380v/440v/460v/480v/600v/660v/1140v
6. Material: Cast iron/SS304/SS316/SS316L/duplex stainless/super duplex stainless steel/SS904L

10hp 10kw water submersible pump parameters:

(cast iron or SS304/SS316/SS316L/duplex stainless/super stainless steel/SS904L and 380v/440v/480v/

600v/660v/1140v. If you would like to know more, please kindly contact us)

Diameter

Model

Power

Flow rate

Head range

Inch (")

QJ type

kw

hp

m3/h

m

7"

175QJ10-121/9

7.5

10

9-11

96-140

7"

175QJ15-80/6

7.5

10

9-11

64-96

7"

175QJ20-65/5

7.5

10

18-22

56-75

7"

175QJ20-78/6

7.5

10

18-22

67-90

7"

175QJ25-65/5

7.5

10

23-27

53-76

7"

175QJ32-48/4

7.5

10

29-35

40-56

7"

175QJ40-36/3

7.5

10

37-43

28-42

7"

175QJ50-36/3

7.5

10

46-54

28-42

8"

200QJ15-81/6

7.5

10

13-17

68-92

8"

200QJ20-65/5

7.5

10

18-22

55-75

8"

200QJ20-81/6

10

14

18-22

66-94

8"

200QJ25-56/4

7.5

10

23-27

45-67

8"

200QJ32-48/3

7.5

10

23-27

38-58

8"

200QJ32-52/4

7.5

10

23-27

42-62

8"

200QJ32-64/4

10

14

29-35

54-77

8"

200QJ32-65/5

10

14

29-35

52-78

8"

200QJ40-39/3

7.5

10

37-43

34-46

8"

200QJ40-45/3

7.5

10

37-43

32-48

8"

200QJ40-52/4

10

14

37-43

45-62

8"

200QJ50-30/2

7.5

10

46-54

24-36

8"

200QJ50-39/3

10

14

46-54

31-47

8"

200QJ50-45/3

10

14

46-54

36-54

8"

200QJ63-42/3

10

14

58-68

24-33

8"

200QJ80-22/2

7.5

10

74-86

19-25

8"

200QJ100-15/1

7.5

10

80-120

12-16

10"

250QJ50-33/2

7.5

10

46-54

28-38

10"

250QJ80-20/1

7.5

10

74-86

17-23

10"

250QJ100-18/1

7.5

10

80-120

16-21

Applications:
1. Ground water pumping
2. Irrigation system
3. Sea water, shipyard, offshore, floating dock, salt water
4. Drawing water from well

10 Hp 10kw Borehole Stainless Steel Submersible Well Pump AC 3 Phase 50hz / 60hz Frequency

APK pump factory not only manufacture water pumps, but also manufacture match pump accessories, including pump control cabinet, frequency converter(ABB or as per request), cable, valve.

10 Hp 10kw Borehole Stainless Steel Submersible Well Pump AC 3 Phase 50hz / 60hz Frequency

FAQ:

1. What's your MOQ?

one piece

2. What's your deliver method?

Sea freight, express, airplane

3. What's your payment?

T/T
