Cast Iron Water Bottom Suction Mine Submersible Pump 800m3/h 75m 300kw 400hp Bomba
Cast Iron Water Bottom Suction Mine Submersible Pump 800m3/h 75m 300kw 400hp Bomba
Cast Iron Water Bottom Suction Mine Submersible Pump 800m3/h 75m 300kw 400hp Bomba
Cast Iron Water Bottom Suction Mine Submersible Pump 800m3/h 75m 300kw 400hp Bomba
Specifications
Brand Name :
APK
Model Number :
QK
Certification :
ISO9001;ISO14001;CE,BV; TUV; SGS; five stars after-sale service
Place of Origin :
Henan, China
MOQ :
1 piece
Price :
please kindly contact us
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
8751 pieces one month
Delivery Time :
3-5 working days after payment confirmation
Packaging Details :
Mine submersible pump is packed by export wooden case
Diameter :
24 inches submersible pump
Flow :
800m3/h
Head :
75m
Motor power :
300kw 400hp water submersible pump
Voltage :
480v 60hz
Material :
Cast iron
Warranty :
24 months
ODM OEM :
Accept
Description

Cast Iron Water Bottom Suction Mine Submersible Pump 800m3/h 75m 300kw 400hp Bomba

Mine submersible pump parameters:

(It is regular submersible pump type in Shenlong pump factory, stainless steel 304/316/316l/duplex stainless/ss904L and 380v/440v/480v/600v/660v/1140v, etc. Please kindly choose submersible pump type you are interested.)

Flow range Head range Power Ranted Current
m3/h m kw hp A
233-267 72-78 90 120 183.8
233-267 95-105 125 170 242
233-267 120-130 160 220 284.4
305-335 28-32 45 60 94.1
305-335 38-42 63 85 127.9
305-335 57-63 90 120 183.8
305-335 85-95 140 190 249.5
305-335 115-125 185 250 367.1
388-416 48-52 90 120 183.8
460-540 18-22 45 60 94.1
460-540 38-42 90 120 183.8
460-540 77-83 185 250 367.1
750-850 12-20 75 100 131.7
900-1200 12-20 90 120 183.8
600-680 54-58 185 250 367.1
600-680 82-86 260 350 558.2
1100-1400 15-22 110 150 222.1
750-850 48-52 220 300 439.2
750-850 73-77 300 400 622.1
900-1200 38-42 220 300 439.2

Mine submersible pump(vertical or horizontal, large flow), is a new water lifting equipment developed by us , it is widely used to draw water from rivers or lakes, water drainage in mines, construction or rebuilding of urban tap water system, secondary regional water supply systems. This is a bottom suction type of pump.
