80m3/H 40m Fountain Submersible Pump Multistage Deep Well Music Landscape
80m3/H 40m Fountain Submersible Pump Multistage Deep Well Music Landscape
80m3/H 40m Fountain Submersible Pump Multistage Deep Well Music Landscape
80m3/H 40m Fountain Submersible Pump Multistage Deep Well Music Landscape
Specifications
Brand Name :
APK
Model Number :
Fountain Pump
Certification :
ISO; CE; SGS; BV; TUV
Place of Origin :
China
MOQ :
1 set
Price :
Please feel free to contact us
Payment Terms :
T/T, Western Union, L/C, MoneyGram, D/P, D/A
Supply Ability :
5000 pieces per month
Delivery Time :
7-15 working days after payment confirmation
Packaging Details :
Fountain submersible pump is packed with seaworthy export standard plywood case.
Flow :
80m3/h submersible pump
Head :
40m submersible pump
Motor Power :
15kw submersible pump
Feature :
Rewinding
Install :
Horizontal
Material :
Stainless steel 304
Description

80m3/h 40m Fountain Submersible Pump Multistage Deep Well Music Landscape

80m3/h multistage fountain pump models:

(Note: flow rate, head meters, materials and installation, or any special specifications, ODM OEM is available)

Model Flow Head Power Current Max. Dia. Discharge Dia.
QS Series m3/h m KW A mm mm
QS(P)15-14-1.1 15 14 1.1 3.2 156 50
QS(P)40-6-1.1 40 6 1.1 3.2 156 80
QS(P)25-9-1.1 25 9 1.1 3.2 156 65
QS(P)25-12-1.5 25 12 1.5 4.2 156 65
QS(P)40-9-1.5 40 9 1.5 4.2 156 80
QS(P)10-40/3-2.2 10 40 2.2 5.7 170 50
QS(P)15-26-2.2 15 26 2.2 5.7 170 50
QS(P)20-20-2.2 20 20 2.2 5.7 170 65
QS(P)25-17-2.2 25 17 2.2 5.7 168 65
QS(P)40-12-2.2 40 12 2.2 5.7 168 65
QS(P)65-7-2.2 65 7 2.2 5.7 168 90
QS(P)15-34/2-3 15 34 3 7 168 50
QS(P)10-54/3-3 10 54 3 7 170 50
QS(P)25-25-3 25 25 3 7 170 65
QS(P)20-30/2-3 20 30 3 7 168 65
QS(P)40-16-3 40 16 3 7 168 65
QS(P)50-13-3 50 13 3 7 168 90
QS(P)80-7-3 80 7 3 7 187 90
QS(P)65-10-3 65 10 3 7 168 90
QS(P)100-6-3 100 6 3 7 200 90
QS(P)100-65/5-4 10 65 4 10.2 168 50
QS(P)100-72/4-4 10 72 4 10.2 168 50
QS(P)10-81/6-4 10 81 4 10.2 168 50
QS(P)15-54/4-4 15 54 4 10.2 168 50
QS(P)20-40/2-4 20 40 4 10.2 168 65
QS(P)25-30/2-4 25 30 4 10.2 168 65
QS(P)30-30/2-4 30 30 4 10.2 168 65
QS(P)32-26-4 32 26 4 10.2 168 65
QS(P)40-21-4 40 21 4 10.2 168 65
QS(P)50-16-4 50 16 4 10.2 168 90
QS(P)65-13-4 65 13 4 10.2 168 90
QS(P)65-15-4 65 15 4 10.2 168 90
QS(P)80-12-4 80 12 4 10.2 187 90
QS(P)100-9-4 100 9 4 10.2 200 90
QS(P)100-95/7-5.5 10 95 5.5 13.4 187 50
QS(P)10-108/8-5.5 10 108 5.5 13.4 187 50
QS(P)15-65/5-5.5 15 65 5.5 13.4 187 50
QS(P)20-54/3-5.5 20 54 5.5 13.4 187 65
QS(P)25-40/3-5.5 25 40 5.5 13.4 187 65
QS(P)30-40/3-5.5 30 40 5.5 13.4 187 90
QS(P)40-30/2-5.5 40 30 5.5 13.4 187 90
QS(P)40-28-5.5 40 28 5.5 13.4 187 90
QS(P)50-26-5.5 50 26 5.5 13.4 187 90
QS(P)65-20-5.5 65 20 5.5 13.4 187 90
QS(P)65-18-5.5 65 18 5.5 13.4 187 90
QS(P)80-15-5.5 80 15 5.5 13.4 187 90
QS(P)100-12-5.5 100 12 5.5 13.4 200 125
QS(P)120-10-5.5 120 10 5.5 13.4 200 125
QS(P)220-5-5.5 220 5 5.5 13.4 200 150
QS(P)10-121/9-7.5 10 121 7.5 18.6 187 50
QS(P)15-80/6-7.5 15 80 7.5 18.6 187 50
QS(P)20-65/5-7.5 20 65 7.5 18.6 187 65
QS(P)20-75/4-7.5 20 75 7.5 18.6 187 65
QS(P)25-65/5-7.5 25 65 7.5 18.6 187 65
QS(P)30-50/3-7.5 30 50 7.5 18.6 187 65
QS(P)30-54/3-7.5 30 54 7.5 18.6 187 65
QS(P)32-48/4-7.5 32 48 7.5 18.6 187 65
QS(P)40-40/2-7.5 40 40 7.5 18.6 187 90
QS(P)50-30/2-7.5 50 36 7.5 18.6 187 90
QS(P)50-36/3-7.5 50 36 7.5 18.6 187 90
QS(P)65-25-7.5 65 25 7.5 18.6 187 90
QS(P)80-22/2-7.5 80 22 7.5 18.6 187 90
QS(P)100-15-7.5 100 15 7.5 18.6 200 125
QS(P)100-17-7.5 100 17 7.5 18.6 200 125
QS(P)250-8-7.5 250 8 7.5 18.6 200 150

Multistage fountain pump features:

1. Multistage fountain submersible pump is composed of impeller, guide vane (division shell), water inlet joint, water outlet. The Impeller is fixed by taper sleeve or bonding.
2. The submersible motor adopts a water-filled structure, which the inner cavity is filled with clean water for cooling the motor.The stator winding of the motor adopts waterproof electromagnetic wire, which has good water-proof function, while rotor is squirrel-cage structured. The water injection hole and exhausted hole are at the upper part of motor. The motor adopts angular contact bearing, which mainly bear the axial force of the pump and the weight of the rotor. The rotor shaft of the QSP series motor is equipped with a mechanical seal to form a sand control mechanism, which can effectively prevent sand from entering the motor and bearings.

80m3/h multistage fountain pump types:

Multi stage submersible pump impellers, horizontal installation, max flow rate up to 2500m3/hr, max head meters is 600m.

80m3/H 40m Fountain Submersible Pump Multistage Deep Well Music Landscape

Vertical installed, horizontal installed, or diagonal installed.

80m3/H 40m Fountain Submersible Pump Multistage Deep Well Music Landscape

80m3/H 40m Fountain Submersible Pump Multistage Deep Well Music Landscape

FAQ

Q: How long is warranty?

A: About 24 months.

Q: How long is production lead time?

A: Depends on quantity, the normal small amount production is about 7-15 working days, maybe some fountain pump types are in stock.

Q: What’s types of shipping?

A: Usually by sea freight, and will be based on the customer's destination to choose the most favorable way.

Q: What is the shipping terms to provide?

A: Depends on customer's requirements, we can provide different transportation terms, such as EXW, FOB, CIF, DDP. Or we deliver fountain submersible pump to your own forwarder in China.

Q: How can I pay for my items? What is the payment you can provide?

A: Usually by T/T, 50% down payment once PI confirmed, the balance will be paid after inspection and before shipment.

L/C at sight.
