Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale
Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale
Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale
Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale
Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale
Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale
Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale
Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale
Specifications
Place of Origin :
China
Brand Name :
SUCE
Model Number :
MD23S
Packaging Details :
Standard export package for A/B ultraosund
Supply Ability :
1000 Set/Sets per Month Portable Ophthalmic Ultrasound
Price :
$2600.00 - $3,600.00/Sets
Certification :
CE,ISO13485
MOQ :
1pc
Payment Terms :
T/T, Western Union,Payoneer
Delivery Time :
about 10 days
Power Source :
Electric
Warranty :
1 Year, 1 Year
After-sale Service :
Online technical support
Material :
Metal, Plastic
Shelf Life :
1years
Quality Certification :
Weee
Instrument classification :
Class I
Safety standard :
EN 149 -2001+A1-2009
Type :
Ophthalmic Optical Equipments
Display :
12.1"
B/W Display :
High-Resolution LCD Color Screen
Probe Frequency :
10MHz, 20MHz
Scanning Angle :
53 Degree
Zoom :
10MHz: 27-60mm, 20MHz: 18-40mm, 6 steps adjustable
Variable Delay Depth :
0~15mm
Probe Protection :
Over 5 minutes
Gray Scale :
256
Description

Hand-held Ultrasounic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale

Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale

Product Description

l Clinical Aplication

This product is intended for ophthalmological ultrasonic diagnosis and AL biometric measurement.

l Components

This product consists of a main unit, application software, a 10MHz A-Scan probe, a 10MHz B-Scan probe, a 20MHz B-Scan probe, a footswitch, a mouse, a keyboard and a power adaptor. The applied parts are 10MHz A-Scan probe, 10MHz B-Scan probe and 20MHz B-Scan probe.

l Certificate:

CF, CE,

l Accessories:

B Probe of 20MHz;Eye cup;Immersion Shell;Trolley;Video Printer;Laser Printer

l Features:
·High Definition 20MHz B-scan Image
·High Resolution LCD touch screen
·Image/video snapped and stored in real time
in multiple buffer slots for immediate comparison and review
·Multiple TGC options for operator's preference including
vitreous-enhanced mode
·Editable clinical report with A-scan/IOL results, B-scan images,
and textual comments with configurable entries
·Reports in. PDF format for sharing and print-out
·Compatibility with graph/text printer
·Diverse connections via HDMI and USB 2. 0 ports
·HDMI interface for double-screen showcase

Hand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for SaleHand-held Ophthalmic A / B Scanner for Ophthalmology Price / Professional Ophthalmic Ultrasound for Sale

General Description
Display 12.1"
B/W Display High-Resolution LCD Color Screen
Touch Screen Yes
Display Mode B, B+A, A
Pedal Yes
B Scan Specification
Probe Frequency 10MHz, 20MHz
Scanning Method Mechanical Sector Scanning
Scanning Angle 53 Degree
Gain 1-105dB Adjustable
Zoom 10MHz: 27-60mm, 20MHz: 18-40mm, 6 steps adjustable
TGC

Default Mode, Vitr Enhance Mode,

Custom Mode
Variable Delay Depth 0~15mm
Dynamic Replay 10s/100 frames (or longer)
with Dynamic Replay
Pseudo Color Yes, 8 color codes
Measurement Distance, Area, Angle
Post Processing No.
Probe Protection Over 5 minutes
Gray Scale 256
A Scan Specification
Probe Frequency 10MHz, with fixation red light
Gain 1~60dB
Biometer Accuracy ≤±0.05mm;
Measuring Range 15 mm~40mm
Measuring Method Contact/Immersion
Measuring Parameters

Anterior Chamber Depth, Lens Thickness,

Vitreous Length, Axial Length
Measuring Mode

Automatic (for Normal, Dense Cataract,

Aphakic and Special); and Manual
Reading Value Average

Calculation of 10 groups average

with Standard Deviation under

Special/Manual mode
IOL Specification
IOL Formula SRK/II, SRK-T, BINKHOST-II, HOLLADAY, HOFFER-Q, HAIGIS
Post-op Refractive Calculation Yes
Post-Refractive
Formulae

HISTORY DERIVED, DOUBLE-K/SRK-T, REFRACTION DERIVED, ROSA and

SHAMMAS
Others
Keyboard Wireless Mouse & Keyboard
Weight 10Kg without Trolley
Package Dimension 45*45*24cm
Printer
Compatibility		 PC & Video Printer
Interface HDMI Port, USB Port, Video Output Interface
Storage 500GB
Data Archiving & Management Built-in Patient Database
Report Customizable digital and printed reports
