API 11AX 25-175 RHAM-12-2-2 Diameter 44mm Insert Pump Oilwell Sucker Rod Pump
API 11AX 25-175 RHAM-12-2-2 Diameter 44mm Insert Pump Oilwell Sucker Rod Pump
Specifications
Brand Name :
ZS
Model Number :
20-125 To 30-250
Certification :
API 11AX
Place of Origin :
China,Henan
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
1000sets/month
Delivery Time :
15 work days
Packaging Details :
nude or wooden case
Material :
Carbon Steel
Light :
Customized
Warranty :
1 Year
Processing Type :
Forging
Color :
Customized
Application :
Energy & Mining, Oil mining
Core Component :
Bearing, Pressure vessel, Gear, Pump
Inlet Pressure :
0-10MPa
Lifetime :
10000-20000h
Product Name :
Sucker Rod Pump
Description

API 11AX sucker rod pump

API 11AX 25-175 RHAM-12-2-2 Diameter 44mm Insert Pump Oilwell Sucker Rod Pump

Product Description

Description:

Rod pump:

The Sucker Rod Pump, also known as the "insert pump," is designed with a plunger that is connected to and moves up and down with the sucker rod string. This type of pump offers certain advantages. For instance, Sucker Rod Pump is particularly useful in deep wells where minimizing workover time is crucial. When inspecting the pump, there is no need to remove all the tubing from the well hole, thus allowing for quicker operations and extending the tubing's service life. Additionally, the sucker rod pump is effective in deviated wells due to its "free hanging" state.

There are two main types of scuker rod pumps based on their seating mode: cup hold-down and mechanical hold-down. Cup hold-down pumps and mechanical hold-down pumps differ in how they are secured in place. Dividing them based on their anchored position, we have top hold-down pumps and bottom hold-down pumps, which include both stationary barrel and traveling barrel types..

Tubing Pump:

For tubing pump, the barrel is put in the well to the designed depth with tubing. And then put the plunger into the barrel with sucker rod. Given the tubing size, the bore of the tubing pump is larger than that of the rod pump, so the pump rate is higher. According to seating mode, the rod pump can be divided into three types: THC pump (Stationary Heavy Wall, Cup Seating, Tubing pump), THM pump (Stationary Heavy Wall Mech. Seating, Tubing Pump) and THD pump.

Main Features:

· The pump barrel is machined by using the high quality special purpose blank; the internal surface has the chrome-plating or the nickel phosphorus compound plating to achieve the good intensity, the rigidity, wear-resistance and anti-corrosion.

· The plunger surface uses the nickel base alloy powder to spurt welding to achieve good wear-resistance and anti-corrosion ability.

· The valve balls and valve seats are made of different materials such as excellent corrosion-resisting stainless steel, tungsten carbide hardness alloy and metal ceramic material to achieve longer life span.

· The pump efficiency is high, pump inspection cycle is longer.

· Simple structure with easy installation and usage.

Technical parameters of pump:

Type

 Main parameters

Dia

(mm)

Length pump

barrel(m)

Length of

stroke(m)

Length of

extension(m)

Tubing pipe

thread

Connect of

sucker rod

Rod pump

 Ø31.8

2.1

2.4

2.7

3.0

3.3

3.6

3.9

4.2

4.5

4.8

5.7

6.0

7.3

8.0

9.1

1.5-

6

0.3

0.6

0.9

 2-3/8” CYG16
Ø38.1

2-3/8”

2-7/8”

 CYG19
Ø44.45

2-3/8”

2-7/8”

 CYG19
Ø57.15 2-7/8” CYG19

Tubing pump

 Ø31.8

1.5-

7.8

0.3

0.6

0.9

 2-3/8” CYG16
Ø38.1

2-3/8”

2-7/8”

 CYG16
Ø44.45

2-3/8”

2-7/8”

 CYG16
Ø57.15 2-7/8” CYG19
Ø69.85 3-1/2” CYG22
Ø95.25 4-1/2” CYG25

Company Information

Puyang Zhongshi Group Co., Ltd is a professional manufacturer of various oilfield equipments and cementing accessories since 1997, restructured enterprise of SINOPEC. Our group have 10 years export experience and 9 subsidiary factories, more than 500 employees. We are the first-class supplier of resources market of SINOPEC and CNPC.

Puyang Zhongshi Group Co., Ltd have the certificates of API 5CT, API 10D, API 11E, API 6A, API 11AX, ISO 9001 and ISO 14001. Our foreign customers are mainly from America, Central Asia, Russia, Southeast Asia, Middle East, etc.
