Corrosion Resistant Oilfield Pump Parts Petroleum Tubing Pump Barrel API 11AX Approved
Corrosion Resistant Oilfield Pump Parts Petroleum Tubing Pump Barrel API 11AX Approved
Corrosion Resistant Oilfield Pump Parts Petroleum Tubing Pump Barrel API 11AX Approved
Corrosion Resistant Oilfield Pump Parts Petroleum Tubing Pump Barrel API 11AX Approved
Specifications
Brand Name :
Zhongshi
Model Number :
Tubing Pump Barrel
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
2000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Product name :
Petroleum Tubing Pump Barrel API 11AX
Tubing size :
15~40 in.co
Pump bore :
125-375
Barrel length :
8-30ft
Plunger length :
2-7ft
Certifications :
API, ISO, QHSE
Description

Corrosion Resistant Oilfield Pump Parts Petroleum Tubing Pump Barrel API 11AX Approved

Product Description

Comparing with conventional tubing pump,The API Tubing Pump has better performance in corrosion resistance & antifriction aspects.Plunger of it is nickel plated on alloy base,inside wall of barrel is plated hard cadmium,key parts,such as valve hood,valve ball,are made of materials with excellent mechanical performance and corrosion resistant property.Compared with conventional pump,the series of pump has a longer working life.

Subsurface pump Per API Spec.11AX

Features

1 API certificate

2 Tubing size:15~40 in.co

3 Pump bore: 125-375
4 Barrel length:8-30ft
5 Plunger length:2-7ft

Main specifications and parameters

Nominal diameter

mm

Length

series of the

plunger

m

Extension

nipple

length

m

Stroke range

of the

plunger

m

O.D. of the

connecting

oil pipe

mm

Diameter of

the connecting

pumping rod

mm

Pump constant

m3/d

Max. O.D.

mm
28

0.6

0.9

1.2

1.5

0.3

0.6

0.9

 0.6-6.0 60.3,73.0 16 0.916 88.9
32 60.3,73.0 16 1.140 88.9
38 60.3,73.0 16/19 1.642 88.9
44 60.3,73.0 19 2.235 88.9
57 73.0 19 3.694 88.9
70 88.9 22 5.518 107
83 101.6 22 7.707 114
95 114.3 25 10.261 121
