Oil Drilling 5 1/2 Oilfield Cementing Tools Bottom Plug Cementing Anti Rotating
Oil Drilling 5 1/2 Oilfield Cementing Tools Bottom Plug Cementing Anti Rotating
Specifications
Brand Name :
Puyang Zhongshi Group
Model Number :
4 1/2"~20"
Certification :
API,ISO,QHSE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, MoneyGram
Delivery Time :
depends on quantity
Packaging Details :
Wooden Box
Product :
Oil Drilling Bottom Anti-rotating Cementing Plugs
Processing :
moulding
Feature :
PDC drillable
Industry :
Energy & Mining
Temperature :
-30℃ to 150℃
Use :
Oil Drilling Rigs, Well drilling
Description

Oil Drilling Bottom Anti-rotating Cementing Plugs

These Cementing Plugs are specially designed with a positive wiping action to ensure that the casing is clean

Oil Drilling Bottom Anti-rotating Cementing Plugs Features

  • Available in sizes from 2-3/8“ up to 20”
  • Available in Pressure Rating from 3,500 PSI up to 8,000 PSI.
  • Manufactured for a standard Burst pressure of 300 PSI and can be adjusted to suit customer requirements
  • Are made of special elastomeric blend that has a good temperature resistance of up to 250°C (482 °F).
Oil Drilling Bottom Anti-rotating Cementing Plugs​ Specification
Casing Size(in) Casing Weight Range Wiper Fin O.D
mm in mm in
4 1/2" 14.14-17.26 9.50-11.60 110 4.331
5" 17.11-35.86 11.50-24.10 122 4.803
5 1/2" 20.83-39.88 14.00-26.80 135 5.315
7" 25.30-56.55 17.00-38.00 170 6.693
7 5/8" 35.72-63.69 24.00-42.00 185 7.283
9 5/8" 53.57-79.62 36.00-53.50 235 9.252
10 3/4" 60.27-97.77 40.50-65.70 260 10.236
13 3/8" 71.43-107.15 71.43-107.15 333 13.11
20" 139.89-197.93 94.00-133.00 498 19.606

Oil Drilling 5 1/2
