Heavy Wall Cup Bottom Seating Sucker Rod Pump
Heavy Wall Cup Bottom Seating Sucker Rod Pump
Specifications
Brand Name :
Zhongshi
Model Number :
Sucker rod pump
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Type of seating assembly :
Cup
Location of seating assembly :
Bottom
Barrel material :
Carbon steel AISI1045
Barrel coating :
Chrome plated
Plunger coating :
Spray metal
API certificate :
API 11AX-0061
Description

Heavy Wall Cup Bottom Seating Sucker Rod Pump

Cup Bottom Seating Sucker Rod Pump Description

Cup bottom seating sucker rod pump is the cup seating assembly rod pump. Sucker rod pump is equipped with a seating nipple(there are two seating nipples in API-RHBM-AC) , seating nipple connection on the tubing string, down to the bottom of the well with the tubing string. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work. Don't need to put out of the tubing string when the sucker rod pump is mantained, only through rod string together put out of the whole pump, operation is simple.

Technical parameter list:

Specification Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in)
15-106RHBC Ø26.99 1.9"
20-125RHAC Ø31.75 2.1-10 0.3-8.0 1.2-9.0 0.3-0.9 2-3/8”
20-125RHBC
25-150RHAC Ø38.10 2-7/8”
25-150RHBC Ø38.10
25-175RHAC Ø44.45
25-175RHBC
30-225RHBC Ø57.15 3-1/2"
30-225RHAC

Features


1. Cup type seating assembly.
2. The material of cup seating assembly is composite, so the cup seating sucker rod pump is suitable for oil well with lower temperature
3. The pump barrel is heavy walled, so the pump is endurable.

Heavy Wall Cup Bottom Seating Sucker Rod Pump
