Oilfield Tubing Pump With Good Corrosion Resistance Environmental Protection
Oilfield Tubing Pump With Good Corrosion Resistance Environmental Protection
Oilfield Tubing Pump With Good Corrosion Resistance Environmental Protection
Oilfield Tubing Pump With Good Corrosion Resistance Environmental Protection
Oilfield Tubing Pump With Good Corrosion Resistance Environmental Protection
Oilfield Tubing Pump With Good Corrosion Resistance Environmental Protection
Specifications
Brand Name :
Zhongshi
Model Number :
TH(B)M
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Machine type :
Petroleum Machinery
Application :
petroleum production
Color :
Required
Type :
Tubing Pump
Certificate :
API 11 ax
Delivery Time: :
Depends on quantity
Description

Oilfield Tubing Pump With Good Corrosion Resistance Environmental Protection

Product description

The downhole sequence of the tubular pump: the tubular pump is divided into two parts: the pump assembly and the plunger assembly. C34 is the tubing coupling. The pump assembly is connected to the bottom of the tubing string through C34 and goes down into the well along with the tubing string. . The plunger assembly is attached to the sucker rod column through the C11 upper travel valve cover and is lowered into the well.

Technical parameter list

Pump designation Pump Bore(in) Length of Plunger (mm) Range of Stroke (mm) Pump Constant (m3/d) Size of matched tubing (in) Size of connecting Sucker Rod(mm) Length of extension Coupling
25-125 1.25 600-1200 600-1200 1.14 2-1/2 2-7/8 16 300-900
25-150 1.5 1.642 2-1/2 2-7/8 16
25-175 1.75 2.235 2-1/2 2-7/8 16
20-175
25-225 2.25 3.694 2-7/8 19
25-275 2.75 5.518 2-7/8 22
30-275 2.75 5.518 3-1/2 22
30-325 3.25 7.707 3-1/2 22
30-375 3.75 10.261 3-1/2 25
40-375 3.75 10.261 4 25

Pictures

Oilfield Tubing Pump With Good Corrosion Resistance Environmental Protection
