Stable Performance Oil Field Pump With Barrel Assembly Easy Operation API 11Ax Standard
Stable Performance Oil Field Pump With Barrel Assembly Easy Operation API 11Ax Standard
Stable Performance Oil Field Pump With Barrel Assembly Easy Operation API 11Ax Standard
Stable Performance Oil Field Pump With Barrel Assembly Easy Operation API 11Ax Standard
Specifications
Brand Name :
Zhongshi
Model Number :
Sucker rod pump
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Standard :
API 11Ax
Size :
30-275THC
Plunger :
P23-275
Barrel :
B13-275
Color :
Customized
Name :
Sucker Rod Pump
Description

Stable Performance Oil Field Pump With Barrel Assembly Easy Operation API 11Ax Standard

Product Description

The barrel assembly of tubing pump is connected directly fixed on the tubing string, and with the pump down to the bottom. Plunger assembly is connected with rod string and down into the bottom hole pump barrel, moving up and down, so as to realize the production process.
In the process of production, when traveling valve and standing valve have problems , they can be put out of the well through the rod string, plunger and puller, without put the whole pump and tubing string out of the well, reduce the labor intensity of operation, reduce the operation cost.

Technical Specifications:

Model mm(in)Nominal Dia. m(ft)Plunger Length Stroke m m3/d Pump Constant Tubing And Thread In Sucker Rod
20-125TH 32(1.25)

1.2-1.8

(4-6)

 0.6-7.3 1.14 2⅜NU/EU ¾
25-125TH 32(1.25) 0.6-7.3 1.14 2⅞NU/EU ¾
20-150TH 38(1.50) 0.6-7.3 1.64 2⅜NU/EU ¾
25-150TH 38(1.50) 0.6-7.3 1.64 2⅞NU/EU ¾
20-175TH 44(1.75) 0.6-7.3 2.24 2⅜NU/EU ¾
25-175TH 44(1.75) 0.6-7.3 2.24 2⅞NU/EU ¾
25-225TH 57(2.25) 0.6-7.3 3.69 2⅞NU/EU ¾
30-275TH 70(2.75) 0.6-7.3 5.50 3½NU/EU ⅞
35-325TH 83(3.25) 0.6-7.3 7.70 4NU/EU ⅞
40-375TH 95(3.75) 0.6-7.3 10.26 4½NU/EU 1

Features


It is suitable for corrosion and small amount of sand and gas, deep Wells, such as complex well conditions, the use of safe, stable performance and wide application.
Under operation easy to operate, economical and practical, it can reduce oil field operation cost by more than 30%.
It can be designed according to the customer’s well.

Operating principle of tubing pumps:

The pump barrel assembly directly fixed on a tubing string. the plunger assembly connected on the sucker rod string ,and with the up and down reciprocating motion, so as to realize the production process. Its advantage lies in: in the process of oil production, when the traveling valve and fixed valve side problem,valve side can be proposed by the sucker rod, piston and extractor , don’t put the whole pump and tubing string out of the well, reduce the work intensity and the operation cost

Stable Performance Oil Field Pump With Barrel Assembly Easy Operation API 11Ax Standard
