EUE Thread API 5CT Pup Joint Casing High Tensile Strength 2.87 - 30mm Thickness
EUE Thread API 5CT Pup Joint Casing High Tensile Strength 2.87 - 30mm Thickness
EUE Thread API 5CT Pup Joint Casing High Tensile Strength 2.87 - 30mm Thickness
EUE Thread API 5CT Pup Joint Casing High Tensile Strength 2.87 - 30mm Thickness
Specifications
Brand Name :
zhongshi
Model Number :
pup joint
Certification :
API 5CT ,ISO ,QHSE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
2 weeks
Packaging Details :
exported packing
Material :
alloy steel,J55 K55 N80 L80 P110
Product name :
API 5ct casing and tubing pup joint
Standard :
API, ISO,QHSE
Thread :
EUE , NUE
Thickness :
2.87-30mm,4.24--20.62mm
Size :
2-3/8-----3-1/2
Description

API 5CT Casing And Tubing 2 7 8 EUE Pup Joint For Oilfield Alloy Steel J55 K55 N80 L80 P110

Product Description:

Tubing pup joints are available upset with 8rd thread, color coded according to class and tensile strength, and manufactured according to API Spec 5CT.Also our group provide the oilfield products which include: subsurface sucker rod pump, pumping unit, cementing tools, wellhead (Christmas Tree),float shoe&collar,centralizer,sucker rod,pup joint,pony rod..etc

Features:

1. Grade:J55, K55, N80-1, N80-Q, L80, C90, P110
2. We also supply permium thread products by customer's request
3. Size: tubing coupling from 1.9" to 4-1/2",Casing coupling fro4-1/2"to 13-3/8"
4. Type: NU, EU(tubing coupling), STC,LC,BTC(casing coupling).
5. Surface treatment: Whole phosphating, or inside phosphating and outside coating
6. Packing: By carton, wooden case, wooden pallet, or by requirements of customers

7.Length: 2ft 4ft 6ft 8ft 10ft 12ft

8.Size: tubing:1.9"- 4 1/2" casing 4 1/2"-13 3/8"

9.Grade:P110 K55 J55 L80 N80

10.Packing: By carton,wooden case,wooden pallet,or by requirements of customers.

11.Thread:EU NU LTC BTC STC


Technical Parameter:

Diameters: 1.9" through 4.5" nominal O.D.
Weights: Standard or Heavy Wall
Lengths: 2, 3, 4, 6, 8, 10, 12 ft. Standard
(Other lengths available upon request)
Grades: J-55, N-80, N-80 Q & T, L-80, P-110
Connections: EUE, NUE, Buttress

Size

Type of Thread

O.D*L (mm)

Weight(kg)
2-3/8" NUE 73.02*107.95 1.28
2-3/8" EUE 77.80*132.82 1.55
2-7/8" NUE 88.90*130.18 2.34
2-7/8" EUE 93.17*133.35 2.40
3-1/2" NUE 107.95*142.88 3.71
3-1/2" EUE 114.30*146.05 4.10
4" NUE 120.65*146.05 4.35
4" EUE 127.00*152.40 4.82
4-1/2" NUE 132.08*155.58 4.89
4-1/2" EUE 141.30*158.75 6.05


EUE Thread API 5CT Pup Joint Casing High Tensile Strength 2.87 - 30mm Thickness
