L80 Alloy Steel Seamless Casing Pipe Oil Country Tubular Goods LTC STC BTC Threads
L80 Alloy Steel Seamless Casing Pipe Oil Country Tubular Goods LTC STC BTC Threads
Specifications
Brand Name :
Zhongshi
Model Number :
4 1/2"-20"
Certification :
API 5CT, ISO, QHSE
Place of Origin :
China
MOQ :
1 metric ton
Price :
Negotiable
Payment Terms :
T/T, L/C
Packaging Details :
Be bundled by steel strap
Function :
Oil well wall cementing
Material :
Quality alloy steel
Application :
Oil drilling
Processing :
Hot-rolled
Place of origin :
China (mainland)
Surface treatment :
Paint
Description
L80 Alloy Steel Seamless Casing Pipe Oil Country Tubular Goods LTC STC BTC Threads


Oil casing description:

Casing pipe is the major structural component of a well. The API 5CT Casing pipe is a large-diameter

steel pipe that serves as the structural retainer for the walls of oil and gas wells, and typically held into

place with cement.

API 5CT casing is inserted into a well bore and cemented in place to protect both subsurface formations

and the wellbore from collapsing and to allow drilling fluid to circulate and extraction to take place.

The cost of casing is a major part of the overall well cost, so selection of casing size, grade, connectors,

and setting depth is a primary engineering and economic consideration.



Features:

1. Oil special pipe
2. International standard API 5CT


Technical specification:

Size

Linear Mass

lb/ft

 Outside Diameter Wall Thickness Type of end-finish
inch mm inch mm Grade
J-55 K-55 M-65 L-80 C-95 N-80 1,Q P-110
4 1/2'' 9.5 4.5 114.3 0.205 5.21 PS PS - - -
10.5 4.5 114.3 0.224 5.69 PSB PSB - - -
11.6 4.5 114.3 0.25 6.35 PSLB PLB PLB PLB PLB
13.5 4.5 114.3 0.29 7.37 -- PLB PLB PLB PLB
15.1 4.5 114.3 0.337 8.56 -- - - - PLB
5'' 11.5 5 127 0.22 5.59 PS PS - - -
13 5 127 0.253 6.43 PSLB PSLB - - -
15 5 127 0.296 7.52 PSLB PLB PLB PLB PLB
18 5 127 0.362 9.19 -- PLB PLB PLB PLB
21.4 5 127 0.437 11.1 -- PLB PLB PLB PLB
23.2 5 127 0.478 12.14 -- - PLB PLB PLB
24.1 5 127 0.5 12.7 -- - PLB PLB PLB
5 1/2'' 14 5.5 139.7 0.244 6.2 PS PS - - -
15.5 5.5 139.7 0.275 6.98 PSLB PSLB - - -
17 5.5 139.7 0.304 7.72 PSLB PLB PLB PLB PLB
20 5.5 139.7 0.361 9.17 -- PLB PLB PLB PLB
23 5.5 139.7 0.415 10.54 -- PLB PLB PLB PLB
26.8 5.5 139.7 0.5 12.7 -- - - - -
29.7 5.5 139.7 0.562 14.27 -- - - - -
32.6 5.5 139.7 0.625 15.87 -- - - - -
35.3 5.5 139.7 0.687 17.45 -- - - - -
38 5.5 139.7 0.75 19.05 -- - - - -
40.5 5.5 139.7 0.812 20.62 -- - - - -
43.1 5.5 139.7 0.875 22.23 -- - - - -
6 5/8'' 20 6.625 168.28 0.288 7.32 PSLB PSLB - - -
24 6.625 168.28 0.352 8.94 PSLB PLB PLB PLB PLB
28 6.625 168.28 0.417 10.59 -- PLB PLB PLB PLB
32 6.625 168.28 0.475 12.06 -- -- PLB PLB PLB
7 3/4'' 46.1 8.625 219.08 0.595 15.11 - - P P P
8 5/8'' 24 8.625 219.08 0.264 6.71 PS PS - - -
28 8.625 219.08 0.304 7.72 - PS - - -
32 8.625 219.08 0.352 8.94 PSLB PSLB - - -
36 8.625 219.08 0.4 10.16 PSLB PSLB PLB PLB PSLB
8.625 219.08 0.45 11.43 - PLB PLB PLB PLB -
44 8.625 219.08 0.5 12.7 - - PLB PLB PLB
49 9.625 244.28 0.557 14.15 - - PLB PLB -
9 5/8'' 32.3 9.625 244.48 0.312 7.92 - - - - -
36 9.625 244.48 0.352 8.94 PSLB PSLB - - -
40 9.625 244.48 0.395 10.03 PSLB PSLB PLB PLB PLB
43.5 9.625 244.48 0.435 11.05 - PLB PLB PLB PLB
47 9.625 244.48 0.472 11.99 - PLB PLB PLB PLB
53.5 9.625 244.48 0.545 13.84 - - PLB PLB PLB
58.4 9.625 244.48 0.595 15.11 - - PLB PLB -
59.4 9.625 244.48 0.609 15.57 - - - - -
64.9 9.625 244.48 0.672 17.07 - - - - -
70.3 9.625 244.48 0.734 18.64 - - - - -
75.6 9.625 244.48 0.797 20.24 - - - - -
10 3/4'' 32.75 10.75 273.05 0.279 7.09 - - - - -
40.5 10.75 273.05 0.35 8.89 PSB PSB - - -
45.5 10.75 273.05 0.4 10.16 PSB PSB - - -
51 10.75 273.05 0.45 11.43 PSB PSB PSB PSB PSB
55.5 10.75 273.05 0.468 12.57 - PSB PSB PSB PSB
60.7 10.75 273.05 0.545 13.84 - - - - PSB
65.7 10.75 273.05 0.595 15.11 - - - - PSB
73.2 10.75 273.05 0.672 17.07 - - - - -
79.2 10.75 273.05 0.734 18.64 - - - - -
85.3 10.75 273.05 0.797 20.24 - - - - -
11 3/4'' 42 11.75 298.45 0.333 8.46 - - - - -
47 11.75 298.45 0.375 9.53 PSB PSB - - -
54 11.75 298.45 0.435 11.05 PSB PSB - - -
65 11.75 298.45 0.534 13.56 - - P P P
71 11.75 298.45 0.582 14.78 - - P P P
13 3/8'' 48 13.375 339.73 0.33 8.38 - - - - -
54.5 13.375 339.73 0.38 9.65 PSB PSB - - -
61 13.375 339.73 0.43 10.92 PSB PSB - - -
68 13.375 339.73 0.48 12.19 PSB PSB PSB PSB PSB
72 13.375 339.73 0.514 13.06 - - PSB PSB PSB
18 5/8'' 87.5 18.625 473.08 0.435 11.05 PSB PSB - - -
20'' 94 20 508 0.438 11.13 PSLB PSLB - - -
106.5 20 508 0.5 12.7 PSLB PSLB - - -
133 20 508 0.635 16.13 PSLB - - - -

Mechanical properties:

Standard Grade Tensile Strength(MPa) Yield strength(MPa) Elongation(%) Hardness
API SPEC 5CT J55 ≥517 379~552 According to API 5CT
K55 ≥655 379~552
N80 ≥689 552~758
L80(13Cr) ≥655 552~655 ≤241HB
P110 ≥862 758~965

L80 Alloy Steel Seamless Casing Pipe Oil Country Tubular Goods LTC STC BTC Threads
