Oilfield Sucker Rods Wheeled Rod Guides For Tubing Roller Centralizer
Oilfield Sucker Rods Wheeled Rod Guides For Tubing Roller Centralizer
Specifications
Brand Name :
Zhongshi
Model Number :
Wheeled Rod Guides
Certification :
API ,ISO ,QHSE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
1000pcs
Delivery Time :
2weeks
Packaging Details :
exported packing
Type :
Wheeled Rod Guides
Size :
1 1/8",3/4",1",5/8"-1-1/8"
Grade :
D,KD,HY,K,HL
Material :
alloy steel,AISI 4130
Length :
25-30ft,. or customized
Product name :
Alloy Steel Sucker Rod
Description

API Wheeled Rod Guides For Sucker Rod & Tubing Roller Centralizer

Tech Parameter

Specification DIMENSIONS(INCH)
Diameter Length Length of the groove
5/8''ROD/2-3/8''TUBING 1.50 27 1.80
3/4''ROD/2-3/8''TUBING 1.50 27 1.80
5/8''ROD/2-7/8''TUBING 1.50 27 2.25
3/4''ROD/2-7/8''TUBING 1.50 27 2.28
7/8''ROD/2-7/8''TUBING 1.625 27 2.28
1''ROD/2-7/8''TUBING 2.0 29 2.28
3/4''ROD/3-1/2''TUBING 1.50 31 2.75
7/8''ROD/3-12''TUBING 1.625 31 2.75
1''ROD/3-1/2''TUBING 2.0 31 2.75

Temperature Caution

Standard models are for applications in wellbore temperature up to 175°F. (fitted with glass-fiber reinforced nylon 6 wheels), For service in higher temperature, Special metal wheels are used.

Materials

Guide/Coupling Body

Standard guide/coupling bodies are machined from 35CrMo.

Special Material

Other metals such as steel are available on Special 'order to meet some

specifications for extra strength and/or corrosion resistance,

Wheel and Roll Pins

Wheels are set on stainless Steel journals and roll pine, Standard wheels, for applications up to 175°F are made of glass-fiber reinforced nylon 6
