Top And Bottom Cup Seating Sucker Rod Pump Stationary Barrel
Top And Bottom Cup Seating Sucker Rod Pump Stationary Barrel
Specifications
Brand Name :
Zhongshi
Model Number :
Sucker rod pump
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Barrel type 1 :
Heavy wall or thin wall
Seating type :
Cup seating
Seating location :
Top or bottom
Barrel structure :
Stationary
Model 1 :
RHAC
Model 2 :
RHBC
Model 3 :
RWAC
Description

Top And Bottom Cup Seating Sucker Rod Pump

Cup seating sucker rod pump description:


Sucker rod pump is classified into cup seating and mechanical seating. The model of cup seating is as follows,

API-RHAC, Rod, Stationary Heavy Wall Barrel, Cup Top Anchor Pump

API-RHBC, Rod, Stationary Heavy Wall Barrel, Cup Bottom Anchor Pump

API-RWAC, Rod, Stationary Thin Wall Barrel, Cup Top Anchor Pump

The cup seating location is on top or at bottom, but the cup seating type is just suitable for the oil well of lower temperature

Rod pump should be installed inside the tubing with the sucker rod.

Sucker rod pump technical parameters:

Item Sucker rod pump
Certificate API 11AX-0061
Type Rod pump, insert pump
Material Carbon steel for main parts, or as customer's request
Processing equipments 1. CNC turning machine
2. Chrome plating machine
3. Metal spray welding machine
4. Spraying metal remelting machine
5. Honing machine
6. Grinding machine
7. Hydraulic Pressure testing pump
Shape Cylinder
Barrel length 2.1-10ft
Pump OD 28 mm to 108 mm
Tensile strength 90000-173339 psi
Yield strength 60000-115000 psi
Barrel

Chrome plating technology

Nickel carbide plating technology
Plunger coating Spray metal or chrome plated surface
Valve seat and ball Stainless steel, tungsten carbide and stellite

Features

1. Can't be used in high temperature enviroment.

2. Production cost is lower than the mechanical seating type
3.Top seating suitable for sandy wells; bottom seating suitable for deep wells.

Top And Bottom Cup Seating Sucker Rod Pump Stationary Barrel
