Heavy Wall Sucker Rod Pump Mechanical Bottom Anchor
Heavy Wall Sucker Rod Pump Mechanical Bottom Anchor
Specifications
Brand Name :
Zhongshi
Model Number :
RHAC
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Model :
RHBM
Anchor type :
Mechanical
Anchor location :
Bottom
Barrel type :
Stationary
Application :
Oil production
Plunger material :
Carbon steel
Description

Heavy Wall Mechanical Bottom Anchor Rod insert Pump

Heavy wall mechanical bottom anchor rod insert pump description

The sucker rod inserted pump's application cover very low downhole pressure wells, slim holes, multiple completions, high temperature and viscous oil. The barrel of all the rod pump is stationary.

Useful specialty pumps include the following:

  • Casing pump for production without tubing
  • Pumps with two plungers that act in series to increase displacement
  • High-compression plunger assembly or pump for handling gas-interference problems
  • Three-tube pump for handling fines or solids
  • Pumps with a shorter barrel than normally recommended, so that the plunger completely wipes solids free of the barrel and prevents sticking.

RH SERRIES
Heavy Wall pump is an API all precision steel pump
O.D. threads for pump extensions
Extension available on both ends, and proper spacing will allow it to be a stroke through pump
the "RH" barrel has a wall thickness of 3/16" or 1/4"
RW SERIES
Thin Wall pump is an API all precision steel pump
The pump has I.D. threads
The "RW" barrel has a wall thickness of 1/8"
Used to maximize production for an insert pump

Technical parameters

Some Models Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in) Sucker rod size
15-106RHBC Ø26.99 2.1-10.4 0.3-8.0 1.2-9.0 0.3-0.9 1.9”

CYJ16

CYJ19
20-125RHBC Ø31.75 2-3/8”
25-150RHBC Ø38.10 2-7/8”
25-175RHBC Ø44.45 2-7/8”
30-225RHBC Ø57.15 3-1/2”

Variables influence:

  • Stresses on the pump
  • Type of pump used
  • Component metallurgy
  • Pump size
  • Internal-fit tolerance
  • Ability to handle solids/gas

Heavy Wall Sucker Rod Pump Mechanical Bottom Anchor
