SL120 Solder Paste Printing Machine 3kw Full Automatic SMT Screen Printer
SL120 Solder Paste Printing Machine 3kw Full Automatic SMT Screen Printer
Specifications
Brand Name :
Suneast
Model Number :
SL120
Certification :
CE、ISO
Place of Origin :
Shenzhen, Guangdong Province, China
MOQ :
≥1 pc
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
25~50 days
Packaging Details :
Plywood crate
Name :
Screen Printing Machine
Model :
SL120
Machine Dimension :
2350(L)*1350(W)*1590(H)mm
Weight :
Approx.1500Kg
Total Power :
Approx.3kw
Main Power Supply :
AC 220V±10% 50/60HZ Single phase
Main Air Supply :
4.5～6kgf/cm2
Min PCB :
80(X)×50(Y) (mm)
Max PCB :
1200(X)×360(Y) (mm)
Conveyor Height :
900±40mm
Conveyor Speed :
0~1500mm/sec, increment 1mm
Print Speed :
5-200mm/s adjustable
Cycle Time :
<10s (ex print, cleaning time)
Customizable :
Yes
Description

Stable Printing Quality SL120 Full Automatic Screen Printing Machines

Solder paste printing machines are mainly used to print solder paste on the surface of circuit boards (PCBs). Apply solder paste evenly onto the solder pads of the circuit board using tools such as scrapers, providing precise and uniform solder paste distribution for subsequent electronic component soldering. The solder paste printing machine can accurately control the coating position and thickness of solder paste through a high-precision motion control system, ensuring the soldering quality between electronic components and PCBs. Solder paste printing machines are widely used in SMT surface mount production lines in the electronic manufacturing industry.

Features:

  • Perfect solution for large size product printing
  • Simple calibration and maintenance
  • Stable printing quality
  • Independent developed image processing software

SL120 Solder Paste Printing Machine 3kw Full Automatic SMT Screen Printer

Overall diagram:

1 Machine housing module

2 CCD image capture module

3 Stencil lifting module of Z-axis

4 Squeegee printing module

5 Cleaning module

6 Platform fine adjustment module

7 Rail and conveyor module

8 Three color warning lamp

9 Display and input device

Product Parameters:

Basic Parameters Screen Frame Size 1000(X)×300(Y)—1500(X)×650(Y) (mm)
Thickness:20-40mm
Min PCB(mm) 80(X)×50(Y) (mm)
Max PCB(mm) 1200(X)×360(Y) (mm)
Thickness 0.2mm～6mm(Use jig when pcb less than 0.4mm)
Curve <1%(Diagonal measurement)
PCB Backside Part Height 15mm
Conveyor Height 900±40mm
Support Magnetic support, Magnetic piece, Vacuum chamber(Option)
Clamp Side clamp and top clamp
Edge Distance PCB process edge≥2.5mm,without PCB edge(option)
Conveyor Speed 0~1500mm/sec, increment 1mm
Conveyor Belt U type sync belt
Stopper method Air Cylinder
Stopper position Set the PCB stopper position according to the size of board
Flow direction Set by software
Print System Print Speed 5-200mm/s adjustable
Print Head Step motor drive scraper lifting
Scraper Steel scraper,rubber scraper(option)
Scraper Angle 60°
Scraper Pressure 0~20kg
Vision System Substrate Separation

Three-section Substrate Separation

speed:0.1-20mm/s distance:0-20mm
Alignment Position method Mark automatic alignment
Camera

Germany BASLER,1/3”CCD,640*480pixel,pixel size:5.6μmx5.6μm
Acquire image method Up/under double photo
Camera Light Coaxial light, Ring light four kinds light can adjustable
View Range 9mm*7mm
Mark dimensions Diameter or Side length 1mm～2mm,allowable offset 10%
Mark Shape Cir, Rec, or rhombus etc
Mark Position PCB dedicated mark or PCB pad
2D detection Standard
Accuracy Table Adjustment Range X=±10mm,Y=±10mm, θ=±1.5°
Positional Accuracy ±0.01mm
Printing Accuracy ±0.025mm
Time Cycle Time <10s (ex print, cleaning time)
Convert line Time <5min
Programming Time <10min
Control System Computer Configuration Industrial PC,Windows official system
System Language Chinese,English
Pre and next machine Connection SMEMA
User authorization User PW and Senior PW set
Cleaning System Cleaning System Dry and Wet, vacuum model
Liquid Level Detection Liquid level auto alarm detection
Power Parameters Main Power Supply AC 220V±10% 50/60HZ Single phase
Total Power Approx.3kw
Main Air Supply 4.5～6kgf/cm2
Machine Weight Approx.1500Kg
Machine Dimension 2350(L)x1350(W)x1590(H)mm
Option Pneumatic Top Clamp Standard
Top clamp + side clamp For PCB(thickness≤1mm)
Vacuum Adsorption and unloading For PCB(thickness≤1mm) and FPC
Auto tin added /
Auto Loading and Unloading /
Flexible and Universal Support For the double-sided PCB(PCB backside parts Height≤9mm)
Automatic Positioning of screen frame /
PCB Thickness Auto Adjustment Function Standard
Squeegee Pressure Feedback Function /
Air conditioner Customer can buy by themselves

The rest of Solder Paste on the stencil

Monitoring System

 /
SPI close loop SPI close loop
UPS power off protection UPS 15min power off protection
Industry 4.0 Bar code trace function, production analysis etc

Notices:

1.Gas source requirements: 4.5-6kgf/cm²; Inlet pipe Ø≥8mm.

2.Power requirements: single-phase AC 220V±10% 50/60HZ, power cord with 4-6mm², equipped with a 16A well grounded socket.

3.Ground pressure requirement: 1000kg/m².

4.During the installation period, arrange 2-3 people to learn and conduct training assessments.
