JS1000 Twin-shaft Concrete Mixer Hzs60 Free Concrect Batching Plant for Airport Construction
JS1000 Twin-shaft Concrete Mixer Hzs60 Free Concrect Batching Plant for Airport Construction
JS1000 Twin-shaft Concrete Mixer Hzs60 Free Concrect Batching Plant for Airport Construction
JS1000 Twin-shaft Concrete Mixer Hzs60 Free Concrect Batching Plant for Airport Construction
JS1000 Twin-shaft Concrete Mixer Hzs60 Free Concrect Batching Plant for Airport Construction
JS1000 Twin-shaft Concrete Mixer Hzs60 Free Concrect Batching Plant for Airport Construction
Specifications
Brand Name :
SUNNY
Model Number :
HSZ60
Place of Origin :
Hunan
MOQ :
1 set
Price :
USD 110000-150000/ SET
Payment Terms :
L/C, T/T, D/P, Western Union, MoneyGram
Supply Ability :
20 Set/Sets per Month
Delivery Time :
25-30 days
Packaging Details :
container
Maaterial :
cement, crushed stone, sands and so on
Application :
Building Works,Construction Projects,bridges,docks,airport
Control system :
automatic PLC control,totally automatic
Productivity :
≤60m3/h
Mixer :
JS1000 Twin-shaft Concrete Mixer
Warranty :
12 Months
Condition :
New
After-sales service provided :
Engineers available to service machinery overseas,Online support,Video technical support,Field installation,commissioning and training
Description

High Efficiency 60m3/h Stationary Concrete Batching Plant Concrete Mixing Plant

High Efficiency 60m3/h Stationary Concrete Batching Plant Concrete Mixing Plant​

A Sunny Concrete Mixing Plant is a sophisticated and efficient facility designed to produce high-quality ready-mix concrete for various construction applications. This plant integrates several key components, such as a concrete mixer, aggregate bins, cement silos, water and additive dispensers, and a fully automated control system to ensure accurate and consistent batching of materials. It is capable of producing large volumes of concrete while maintaining precision in mix ratios, which is essential for meeting the required strength and durability specifications.

1. Adopting twin-shaft compulsory concrete mixer, ready mixed concrete batching plant mixes evenly and rapidly, achieving good mixing effect for all kinds of dry, semi-dry and plastic concrete;
2. Compact-structured planetary gear was adopted in our ready mixed concrete batching plant to ensure smooth, speedy and efficient transmission;

Advantages of HZS60 Concrete Mixing Plant:

  • High production capacity: Meets the demands of large-scale construction projects.
  • Excellent mixing quality: Produces consistent and high-quality concrete.
  • Efficient operation: Minimizes downtime and maximizes productivity.
  • Durability and reliability: Built to withstand harsh conditions and provide long-lasting performance.
  • Customization options: Can be tailored to specific project requirements.

Name of parameter
HZS60
HZS90
HZS120
HZS180
HZS240
Theoretical productivity
60 M3/h
90 M3/h
120 M3/h
180 M3/h
240m³/h
Model of mixer
JS1000
JS1500
JS2000
JS3000
JS4000
Mixing motor power
2x18.5Kw
2x30Kw
2x37Kw
2x55Kw
2*75Kw
Cycle period
60s
60s
60s
60s
60s
Volume of mixer
1000L
1500L
2000L
3000L
4000L
Unloading height
4.0m
4.0m
4.0m
4.0m
4.0m
Measuring range and precision of aggregate
(600-2000)≤±2%
(700-2400)≤±2%
(1000-3600)≤±2%
(1600-4800)≤±2%
(1600-4800)≤±2%
Measuring range and precision of cement
(300-1200)≤±1%
(300-1200)≤±1%
600-1800)≤±1%
(800-2400)≤±1%
(800-2400)≤±1%
Measuring range and precision of coal ash
(200-600)≤±1%
(200-600)≤±1%
(300-900)≤±1%
(400-1200)≤±1%
(400-1200)≤±2%
Measuring range and precision of water
200-600)≤±1%
(200-600)≤±1%
(200-700)≤±1%
(360-1200)≤±1%
(360-1200)≤±1%
Measuring range and precision of admixture
20-60)≤±1%
(20-60)≤±1%
(30-100)≤±1%
(36-120)≤±1%
(36-120)≤±1%

JS1000 Twin-shaft Concrete Mixer Hzs60 Free Concrect Batching Plant for Airport Construction

Features of concrete batching plant:
1.It adopts combined structure and unitized module, which is short, quick and very convenient for installation and demolition .

2.Increase the unloading angle of the aggregate bin to solve the problem of unloading difficulties caused by rain
3.It is convenient and quick to use the cylinder discharge or electric push rod to discharge.
4.The overall steel structure of the mixing station is made of high-quality steel, which has high overall structural strength and strong stability.
5.The mixing machine adopts the twin-shaft forced mixing main machine, which has strong mixing performance, uniform mixing and high productivity.
6.Excellent pneumatic components, electrical components, etc.; to ensure the reliability of the equipment, accurate metering performance.
7.Each maintenance and repair site is provided with a walking platform or a check ladder, and has sufficient operation space. Easy maintenance and repair 8.Environmental protection and energy saving, using pulse dust removal, recycling waste-water for reuse
