Specifications
Brand Name :
SUNNY
Model Number :
Warehouse Cargo Lift
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
1set
Price :
$7000~12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 Set/ Year
Delivery Time :
15~30 days
Packaging Details :
container
Name :
Cargo Elevator
Load :
1000~3000kg
Speed :
0.5~1.0m/S
Elevator Door :
Sider Door
Door Knife :
Double
Warranty :
12 months after shipping
Material :
Steel Plate
Product name :
Freight Lift
Control :
VVVF Elevator Control System
Keywords :
Freight Lift
Product :
Cargo Elevator
Model :
Cargo Elevator
Description

Painted Steel Cargo Elevator For Carrying Freight Drive Elevator

Machine roomless freight advantages

1 Advanced modern craft & tech greatly reduces the building cost

2 It enhances the utilization rate of the space

3 Enhances the carrying capacity of goods transport.

4 It advocates green high energy-saving.

Configuration parameters

Loading capacity(kg) 1000 1600 2000 3000
Rated speed(m/s) 0.63 1.0 0.5 0.5 0.5
Door opening size
4 panel center opening
1200*2100 1500*2100 1500*2100 2000*2100
Traction ratio 2:1 4:1 4:1 4:1
Car size(mm) Width 1600 1500 1500 2000
Depth 1500 2300 2700 2800
Height 2200 2200 2200 2200
Hositway size(mm) width 2500 2800 2800 2800 3470 3470
Depth 1900 2800 3200 3180 3300 3280
Top floor height(mm) 4200 4500 4500 4500
Pit depth(mm) 1700 1700 1700 1700
Max.travelling height(m) 25 40 20 20 20

VVVF Painted Steel Cargo Elevator For Carrying Freight Drive VVVF Elevator Control System

VVVF Painted Steel Cargo Elevator For Carrying Freight Drive VVVF Elevator Control System

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
