VVVF Gearless Mrl Machine Room Less Elevator 2000kg Load Capacity
VVVF Gearless Mrl Machine Room Less Elevator 2000kg Load Capacity
VVVF Gearless Mrl Machine Room Less Elevator 2000kg Load Capacity
VVVF Gearless Mrl Machine Room Less Elevator 2000kg Load Capacity
Specifications
Brand Name :
SUNNY
Model Number :
Passenger elevator
Certification :
3C,CE
Place of Origin :
China
MOQ :
1 set
Price :
$7000~12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 Set/ Year
Delivery Time :
15~30 days
Packaging Details :
container
type :
Machine Room Less Elevator
Load :
450~2000kg
Speed :
1.0~3.0m/S
Model :
Machine Room Less Elevator
Drive type :
VVVF
Transportation :
Sea Delivery
Elevator parts :
Traction System
Voltage :
380V/220V
Product :
Machine Room Less Elevator
Description
Passenger Elevator With Gearless Traction Machine With High Quality Mechanical Safety
When a person enters a building, the first room to step inside is the elevator .The elevatro plays an important role as a face
deciding the first impression of the building and provides an enjoyable time in traveling from one floor to another .
PRODUCT SPECIFICATIONS
Persons
Rated Capacity(kg)
Speed(m/s)
Cabin Size (W*D*H)
Door Size (W*H)
Shaft Size (W*H)
6
450
1.0-3.0
1400*850*2300
800*2100
2000*1500
8
630
1.0-3.0
1400*1100*2300
800*2100
2000*1720
10
800
1.0-3.0
1400*1350*2300
800*2100
2000*1970
13
1000
1.0-3.0

1600*1450*2300

1100*2100*2300
900*2100

2200*2120

2100*2500
16
1250
1.0-3.0
1900*1450*2300
1100*2100
2500*2150
18
1350
1.0-3.0
1900*1550*2300
1100*2100
2500*2250
21
1600
1.0-3.0
1900*1800*2300
1100*2100
2500*2500
26
2000
1.0-3.0
1900*2200*2300
1100*2100
2700*2700

VVVF Gearless Mrl Machine Room Less Elevator 2000kg Load Capacity

VVVF Gearless Mrl Machine Room Less Elevator 2000kg Load Capacity

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
