30L Water Bottle Molding Machine , PC Plastic Extrusion Blow Molding Machine
30L Water Bottle Molding Machine , PC Plastic Extrusion Blow Molding Machine
30L Water Bottle Molding Machine , PC Plastic Extrusion Blow Molding Machine
30L Water Bottle Molding Machine , PC Plastic Extrusion Blow Molding Machine
Specifications
Brand Name :
SUNRISE
Model Number :
12000 per hour
Certification :
EcoVadis audit, UL certification, SGS certification, Sedex certification, European Union PED, American ASME, German TUV, Russian GOST, European Union ATEX, Australia AS1210, CE, ISO
Place of Origin :
Jiangsu, China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
6 units per year
Delivery Time :
120 days
Packaging Details :
Standard shipping wooden box or stretch film packaging
Max. Product Volume :
30L
Dry Cycle :
650pcs/h
Machine Size :
5.0*2.4*3.8m
Machine Weight :
11.6ton
Installed capacity :
78kw
PC Output :
150KG/H
Clamping Force :
80KN
Action control :
Japan Mitsubishi, programmable
Description

Factory Price 3 Gallon 5 Gallon 25L 30L PC Plastic Mineral Water Bottle Making

Extrusion Blow Molding Machine

Main features:

* Bilingual touch screen: moved by Rotary arm to provide user easy and smart operation

* Double liner guide rail: Unique “liner guide” to the clamping structure to ensure mold-lock uniform, knit line smoother, stable, and quite working.

* Mould locking system: adopts Crank Arm-Center lock design to provide the strong clamping force. Suitable to produce 20-30Lplastic drum, low energy cost, high output.

Product details:

Basic Parameter
Available material PC
Max. Product Volume 30 (L)
Dry Cycle 650 (pcs/h)
Machine Size 5.0*2.4*3.8 (L*W*H)(m)
Machine Weight 11.6 (Ton)
Installed capacity 78 (KW)
PC Output 150 (KG/H)
Plasticizing System
Screw Diameter 82 (mm)
Screw L/D Ratio 25/28 L/D
Screw Drive Power 16 (KW)
Screw Heating Zone 6 (Zone)
Screw Heating Power 6.5 (KW)
Extrusion System
Type Accumulator Die Head
NO. of Heating Zone 4 (Zone)
Die Heating Power 7 (KW)
Max. Die Diameter 180 (mm)
Open and Clamping System
Clamping Force 80 (KN)
Mold Stroke 280-642 (mm)
Mold Template Size 520*580 (W*H)(mm)
Electric Control System
Touch Screen Colorful touch screen, auto alarm, diagnose the system
Temperature Control Self-regulation
Temperature Module Taiwan I-7018RP automatic temperature module, digital
Action control Japan Mitsubishi, programmable
