A grade poly solar panel 230w / solar module multi-crystalline with competitive price for hot sale
A grade poly solar panel 230w / solar module multi-crystalline with competitive price for hot sale
Specifications
Place of Origin :
China
Brand Name :
Sunsou
Model Number :
GS-P230W
MOQ :
1*20GP
Price :
Get Latest Price
Packaging Details :
1box/pallet
Delivery Time :
10 days
Payment Terms :
TT, Western Union, Money Gram
Supply Ability :
30000/month
Size :
1640*992*45mm
Number of Cells :
60pcs
Max. Power :
230w
Material :
Polycrystalline Silicon
Name :
A grade poly solar panel 230w / solar module multi-crystalline with competitive price for hot sale
Glass :
3.2mm Tempered Low Iron
Backsheet :
Block Humidity and Oxy Effectively
Frame :
Aluminium Alloy
Warranty :
25 years output power guarantee
Type of Connector :
Compatiable Type MC4
Vmp at STC :
30.2V
Imp at STC :
7.62A
Description

A grade poly solar panel 230w / solar module multi-crystalline with competitive price for hot sale

Specification:

A grade poly solar panel 230w / solar module multi-crystalline with competitive price for hot sale

Maximum power at STC(Pmax)

230W

Optimum operating voltage(Vmp)

30.2V

Optimum operating current(Imp)

7.62A

Open-circuit voltage(Voc)

36.9V

Short-circuit current(Isc)

8.22A

Short-circuit current temperature coefficient

(0.065±0.015)%/°C

Open-circuit voltage temperature coefficient

-(80±10)mV/°C

Peak power temperature coefficient

-(0.5±0.05)%/°C

NOCT (Air 20°C; Sun 0.8kW/m wind 1m/s)

47±2°C

Operating temperature

-40°C to 85°C

Maximum system voltage

1000V DC

Cell

Power tolerance

No. of cell and connection

Poly-crystalline siliconsolar cells

±3%

60(6×10)

Dimension of module

Weight

Electrical Characteristics
1640mm*992mm*45mm

19.6kg

GS-P230W

Features:

l Nominal 24V DC for standard output.

l High efficiency.

l Outstanding low-light performance.

l High transmission tempered glass.

l Rugged design to withstands high wind

pressure and snow load, easy installation.

l Aesthetic appearance.

l Design to meet unique demand of customer.

l 25 year module output warranty.

A grade poly solar panel 230w / solar module multi-crystalline with competitive price for hot sale

A grade poly solar panel 230w / solar module multi-crystalline with competitive price for hot sale

1. Payment term: T/T in advance (W/U for sample order)
2. Lead time: It depends on your quantity. Usually we will send sample within 5-7 working days.
3. Shipping will be made via EMS, DHL, Fedex, UPS etc. shipment

A grade poly solar panel 230w / solar module multi-crystalline with competitive price for hot sale

4. Others: If you have special specifications and requirements, we will do different offer as you required.
