Specifications
Brand Name :
ABOOM
Model Number :
UNS S31200
Certification :
EN 10204 Type 3.1
Place of Origin :
CHINA
MOQ :
1000KGS
Price :
USD Negotiable
Payment Terms :
T/T
Supply Ability :
200 TONS per month
Delivery Time :
7-15 days
Packaging Details :
Standard export packaging
TYPE OF MATERIAL :
duplex stainless steel Ferritic /Austenitic Stainless Steel
PRODUCT :
S31200 / SS329 Duplex Stainless Steel Plate
STANDARD :
ASTM A240 or as appropriate
GRADE :
UNS S31200 / 1.4460 / SS329
Manufacturing process :
The steel melt shall be refined with AOD or equivalent.
Heat Treatment :
shall be supplied in the solution annealed/water quenched condition.
Surface Finish :
Descaled, White Pickled, and Passivated Condition
Application areas :
Pulp and paper industry, desalination, flue gas purification, heat exchangers, chemical tanker pipeline systems, seawater systems, etc.
Description

S31200 1.4460 Super Duplex Plate Stainless Steel Acid Corrosion Resistance

S31200 / SS329 Duplex Stainless Steel Plate for Industry 1.4460

Regular size(mm):

Cold rolled sheet
0.5 * 1219 * C

1.0 * 1219 * C

1.5 * 1219 * C
2.0 * 1219 * C

2.5 * 1219 * C

3.0 * 1219 * C


Hot rolled sheet
3.0 * 1500 * c

4.0 * 1500 * c

5.0 * 1500 * c
6.0 * 1500 * c

8.0 * 1500 * c

10 * 1500 * c
12 * 1500 * c

14 * 1500 * c

16 * 1500 * 6000

18 * 1500 * 6000

20 * 1500 * 6000
25 * 1500 * 6000

30 * 1500 * 6000

Special sizes can be customized according to customer requirements

General attributes:

Duplex stainless steel S31200 / 1.4460 / SS329 is a high hardness and high strength duplex stainless steel. It has good plasticity, toughness, weldability and corrosion resistance. It has good corrosion resistance in oxidizing and reducing media.

Material: S31200 / 1.4460 / ss329

The chemical composition of S31200 / 1.4460 / SS329 stainless steel is as follows:

C: ≤0.08 Si: ≤1.00 Mn: ≤2.50 S: ≤0.030
P: ≤0.035 Cr: 23.00 ~ 28.00 Ni: 3.00 ~ 6.00 Mo: 1.00 ~ 3.00


S31200 / 1.4460 / ss329 stainless steel mechanical properties:


Tensile strength σb (MPa): ≥590
Conditional yield strength σ0.2 (MPa): ≥390
Elongation δ5 (%): ≥18
Section shrinkage ψ (%): ≥40

Implementation standards:


ASTM A240 (ASME SA240)

Performance characteristics:
1. Excellent resistance to general corrosion and local corrosion, especially stress corrosion resistance, pitting corrosion resistance, crevice corrosion resistance, corrosion fatigue resistance and wear resistance etc.
2. Good solderability
3. Good comprehensive mechanical properties
4. Good resistance to intergranular corrosion
5. High cost performance and long service life

Application fields are:

It is used to make acid-resistant equipment, such as Corrosion-resistant containers and equipment linings, pipelines, nitric acid-resistant equipment parts, etc..



Delivery form:Plate ,Sheet

S31200 1.4460 Super Duplex Plate Stainless Steel Acid Corrosion Resistance
