Forging Precipitation Hardening Stainless Steel Block NAS630 S17400 17-4PH
Forging Precipitation Hardening Stainless Steel Block NAS630 S17400 17-4PH
Forging Precipitation Hardening Stainless Steel Block NAS630 S17400 17-4PH
Forging Precipitation Hardening Stainless Steel Block NAS630 S17400 17-4PH
Specifications
Brand Name :
ABOOM
Model Number :
NAS630
Certification :
EN 10204 Type 3.1
Place of Origin :
CHINA
MOQ :
1000kgs
Price :
USD Negotiable
Payment Terms :
T/T
Supply Ability :
200 TONS PER MONTH
Delivery Time :
7-15dyas
Packaging Details :
Bare packing/bundle packing with woven bag/wooden or steel frame crate packing/plastic cap protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.
TYPE OF MATERIAL :
Precipitation, hardening, martensitic stainless steel
PRODUCT :
Forging NAS630 S17400 17-4PH precipitation hardened stainless steel block
STANDARD :
GB / T 908 -2008 or as appropriate
GRADE :
UNS630 / 17-4PH / S17400 / SUS630
Manufacturing process :
The steel melt shall be refined with AOD or equivalent.
application :
Bearings, steam turbine parts
Microstructure :
Precipitation hardening
Testing facility :
Accept other third-party testing agencies such as SGS
Description

Forging Precipitation Hardening Stainless Steel Block NAS630 S17400 17-4PH

Forging NAS630 S17400 17-4PH precipitation hardened stainless steel block

Application area:

Offshore platforms, helicopter decks, other platforms
food industry
Pulp and paper industry
Aerospace (turbine blades)
mechanical part
Nuclear waste barrel


The NAS630 S17400 17-4PH alloy is a precipitation, quenched, martensitic stainless steel, and this grade has high strength, hardness (up to 300 0 C / 5000 C) and corrosion resistance. After heat treatment, the mechanical properties of the product are more complete, and it can reach compressive strength of up to 1100-1300 mpa (160-190 ksi). This grade cannot be used above 300 0C (572 0F) or very low temperature. It has good corrosion resistance to the atmosphere and diluted acids or salts. It has the same corrosion resistance as 304 and 430.

3/16" 1/4" 5/16" 3/8" 7/16" 1/2" 9/16" 5/8" 3/4" 7/8" 1"
4.8mm 6.3mm 7.9mm 9.5mm 11.1mm 12.7mm 14.3mm 15.9mm 19mm 22.2mm 25.4mm
1 1/8" 1 1/4" 1 1/2" 1 3/4" 2" 2 1/4" 2 1/2" 2 3/4" 3" 3 1/2" 4"
28.6mm 31.8mm 38.1mm 44.5mm 50.8mm 57.2mm 63.5mm 69.9mm 76.2mm 88.9mm 101.6mm

chemical composition:

C Cr Ni Cu Nb/Cb Mn
0.04 16.5 4.5 3.3 0.3 0.7
PREN (%Cr+3.3%Mo+16%N)≥17

Mechanical properties

Hardened YS 0.2%
N/mm		 UTS
N/mm
Min. Typ. Min. Typ.
A 1070 1207 1170 1310
B 790 931 965 1034
Hardened YS 0.2%
ksi		 UTS
ksi		 El%
Min. Typ. Min. Typ. Min. Typ.
A 155 175 170 190 8 14
B 115 135 140 150 10 17

Hardened at 496 ° C (925 ° F)-4 hours-air cooled
Hardened 593 ° C (1100 ° F)-4 hours-air cooled
The above are two examples of heat treatment.

NAS630 S17400 17-4PH precipitation hardened stainless steel Shaft

Forging Precipitation Hardening Stainless Steel Block NAS630 S17400 17-4PH

Hardness/Temperature tempered for 4 hours after austenitizing at 1040°C (1904°F) for 30 min quenched 100°C/sec (212°F/sec).

Forging Precipitation Hardening Stainless Steel Block NAS630 S17400 17-4PH
