High TG Custom HASL ENIG PCB Printed Circuit Board Assembly
High TG Custom HASL ENIG PCB Printed Circuit Board Assembly
High TG Custom HASL ENIG PCB Printed Circuit Board Assembly
High TG Custom HASL ENIG PCB Printed Circuit Board Assembly
High TG Custom HASL ENIG PCB Printed Circuit Board Assembly
High TG Custom HASL ENIG PCB Printed Circuit Board Assembly
Specifications
Brand Name :
PY
Model Number :
PCB
Certification :
ISO9001
Place of Origin :
ShenZhen
MOQ :
1PCS
Price :
0.1-1USD
Payment Terms :
T/T, L/C, D/P, D/A, Western Union, MoneyGram
Supply Ability :
Ten thousand square meters per month
Delivery Time :
5-10 work days
Packaging Details :
Vacuum packing, high quality carton
Color :
green
Number of plies :
2-4 Layer
Copper Thickness: :
1oz
Base Material: :
FR4 ,Hight TG
Board Thickness: :
0.6～3.2mm
Place of Origin: :
Guangdong, China (Mainland)
surface Finishing: :
HASL(lead Free) / Immersion Gold
Min. Hole Size :
3mil
Service :
Stop Turnkey service,PCBA
Surface finishing :
HASL,ENIG,OSP
Application :
pcb printed circuit board,Consumer Electronics
Description

High TG Custom HASL ENIG PCB Printed Circuit Board Assembly

Capability

　 High precision prototype PCB bulk production
Max Layers 1-28 layers 1-14 layers
MIN Line width(mil) 3mil 4mil
MIN Line space(mil) 3mil 4mil
Min via (mechanical drilling) Board thickness≤1.2mm 0.15mm 0.2mm
Board thickness≤2.5mm 0.2mm 0.3mm
Board thickness＞2.5mm Aspect Ration≤13:1 Aspect Ration≤13:1
Aspect Ration Aspect Ration≤13:1 Aspect Ration≤13:1
Board thickness MAX 8mm 7mm
MIN 2 layers:0.2mm;4 layers:0.35mm;6 layers:0.55mm;8 layers:0.7mm;10 layers:0.9mm 2 layers:0.2mm;4 layers:0.4mm;6 layers:0.6mm;8layers:0.8mm
MAX Board size 610*1200mm 610*1200mm
Max copper thickness 0.5-6oz 0.5-6oz
Immersion Gold/
Gold Plated Thickness		 Immersion Gold:Au,1—8u”
Gold finger:Au,1—150u”
Gold Plated:Au,1—150u”
Nickel Plated :50—500u”		 　
Hole copper thick 25um 1mil 25um 1mil
Tolerance Board thickness Board thickness≤1.0mm:+/-0.1mm
1.0mm<Board thickness≤2.0mm:+/-10%
Board thickness>2.0mm:+/-8%		 Board thickness≤1.0mm:+/-0.1mm
1.0mm<Board thickness≤2.0mm:+/-10%
Board thickness>2.0mm:+/-8%
Outline Tolerance ≤100mm:+/-0.1mm
100< ≤300mm:+/-0.15mm
>300mm:+/-0.2mm		 ≤100mm:+/-0.13mm
100< ≤300mm:+/-0.15mm
>300mm:+/-0.2mm
Impedance ±10% ±10%
MIN Solder mask bridge 　0.08mm 　0.10mm
Plugging Vias capability 　0.25mm--0.60mm 　0.70mm--1.00mm

Applications:


Communications
Traditional telecommunication equipment, FTTP, VOIP, multimedia services, data networking and IT infrastructure products, wireless infrastructure products, power amplifiers, splitters and combiners, high power transistors, etc.

Computer Peripherals
High end printers, cable modem, wireless routers, IP telephones, consumer and office products, banking system etc.

Consumer
Computers, televisions, cameras, digital video recorders (DVR), handheld products, LED, etc.

Automotive
Passenger safety systems, engine control systems, air bags, traction control products, etc.

High End Computing and Storage
High performance computer and server, mainframe system and storage equipment, memory, etc.

Industry


Power supply, main control panel, monitor, CCTV products,automotive control equipment, industry robot, access control products etc

Medical
Magnetic resonance imaging (MRI), computed tomography (CT), emergency response defibrillation units, patient monitoring, implantable devices, robotic surgery systems, biometrics and diagnostic equipment, etc.

Military
Satellite, radar, airplane, control unit, communication equipment .etc.

Test & Measurement
Power meters, electricity tester, thermal tester, light tester, network tester, gas and oil tester, infrared products, semi-conductor test equipment, DUT and probe cards, wafer inspection systems, etc.

High TG Custom HASL ENIG PCB Printed Circuit Board Assembly

High TG Custom HASL ENIG PCB Printed Circuit Board Assembly

High TG Custom HASL ENIG PCB Printed Circuit Board Assembly



High TG Custom HASL ENIG PCB Printed Circuit Board Assembly

High TG Custom HASL ENIG PCB Printed Circuit Board Assembly

Ping You Industrial Co.,Ltd
Ping You Industrial Co.,Ltd is a professional and reliable one-stop PCB solutions provider for customers specialized in manufacturing quick turn prototypes and small volumes.Topfast is responsible for overseas business development.With high quality and on-time delivery products we won the market's wide acclaim. We will continue to focus on customer satisfaction, along with "high quality "and "fast delivery", we will become a PCB service provider worthy of customer trust.

Advantages


1. PCB factory directly
2. Comprehensive quality control system
3. Competitive price
4. Quick turn delivery time from 48hours.
5. Certificates (ISO/UL E354810/RoHS)
6. 10 years experience in exporting service
7. No MOQ/MOV.
8. High quality. Strict through the AOI(Automated Optical Inspection), QA/QC, flying porbe ,Etesting, etc
