FLOWDRIFT Electric Magnetic Drive Stainless Steel Gear Pump G200 YT/YY series

Specifications

Brand Name :

FLOWDRIFT

Model Number :

G200 YT/YY series

Certification :

CE;RoHS

Place of Origin :

China

MOQ :

50pcs

Price :

Negotiable

Payment Terms :

100% prepaid via Paypal/Western Union/ T/T/Alipay

Supply Ability :

5000pcs/month

Delivery Time :

3-15days

Packaging Details :

30*30*25 cm; 15kg

Theory :

Vacuum Pump

Structure :

Gear Pump

Usage :

Water

Power :

Electric

Standard or Nonstandard :

Nonstandard

Fuel :

Electric power, Solar, Battery

Pressure :

High Pressure

Application :

hot water, fuel oils, solvent

Description

FLOWDRIFT^TM Electric Magnetic Drive Stainless Steel Gear Pump G200 YT/YY Series Quiet Working Food Grade for Hot Water 0-100℃ High Viscosity 3000CPS Allowed

Name: FLOWDRIFT Electric Magnetic Drive Stainless Steel Gear Pump G200 YTYY series
Brand: FLOWDRIFT
Price: 1 USD

FLOWDRIFT Electric Magnetic Drive Stainless Steel Gear Pump G200 YT/YY series

G200 (YY / YT) Magnetic drive gear pump is a new gear pump, YT Series gears and super-hard ceramic material made of Alloy, Stainless steel hardening treatment with high-quality manufactured housing composed of a gear pump. YY series of high quality Stainless steel made of hardened gears, shafts and housing the gear pump in a hard particle slurry liquid (such as the use of pigment ink, a liquid containing titanium dioxide), and it works fine. using magnetic coupling drive structural design to solve the gear shaft end leakage problems. it is called non-disclosure of the gear pump is mainly used in the field of traditional Chinese medicine machines, packaging machines, inkjet printing machines, analytical instruments and other trace delivery.

Model specification

Model	G	2	00	Y	T
Position	1	2	3	4	5
1	Pump Type	G = Gear pumps
2	Pump Series	2 = 2 series
3	Gear height	04 = 4mm 09 = 9mm 13 = 13mm
4	Shell material	Y = Stainless steel 316 hardened
5	Gear Material	T = Hard Alloy Y = Stainless steel 316 hardened

Technical parameters

Specifications Model	Displacement (ml / rev)	Maximum pressure (bar)	System pressure (bar)	Rev. range (rpm)	Medium viscosity (cps)
G204YT	0.27	3	-0.8 To 20	500 to 2500	300-1500
G209YT	0.55
G213YT	0.75
G204YY	0.27				300 to 2500
G209YY	0.55
G213YY	0.75

Note: 1, the transmission medium temperature: -30 ℃ ~ 100 ℃ (except frozen); Ambient temperature: -30 ~ 50 ℃.

2, the inner rotor gear pump for NdFeB magnets PPS plastic coated, static sealing material is PTFE; rotor cover material Stainless steel 316.

3, G200YY gear pumps all over the liquid material: are FDA-compliant testing requirements.

4, the work: 24 hours of continuous duty.

5, or may be a high pressure (20bar) used in a closed system under vacuum (-0.8bar).

6, suitable for transporting particles containing pigment ink and paint.

7, suitable diameter containing particles in a liquid solution ≤20 microns

Outline dimension chart:

FLOWDRIFT Electric Magnetic Drive Stainless Steel Gear Pump G200 YT/YY series

Flow graph:
