FLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washer
FLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washer
Specifications
Place of Origin :
China
Brand Name :
FLOWEXPERT
Certification :
CE;RoHS
Model Number :
KDP-32-34
MOQ :
10pcs
Price :
Negotiable
Packaging Details :
1pc/inner color box;20pcs/ctn; Seaworthy strong cartons; 64*39*22.5 cm/ctn; 20kg/ctn
Delivery Time :
10-15days
Payment Terms :
100% prepaid via Paypal/Western Union/ T/T/Alipay
Supply Ability :
50,000pcs/month
Theory :
Vacuum Pump
Structure :
Diaphragm Pump
Usage :
Water
Power :
Electric
Standard or Nonstandard :
Nonstandard
Fuel :
DC Power
Application :
washing, spraying, misting
Pressure :
100PSI
Voltage :
12V/24V
Flow :
1.3GPM (5.1LPM)
Color :
Black/Blue/Orange or as requested
Rated Current :
5A max
Factory :
OEM/ODM
Motor :
BD5590S-8P 12V-3400RPM
Description

FLOWEXPERTTM DC 12V 24V 100psi Miniature High Pressure Diaphragm Pump KDP-32-34 for Sprayer and Wash

APPLICATIONS

  • Water purification,filter machine,chemical metering and fluid supply.
  • High pressure pumps used in sprayers and spray fixtures for high plants.
  • Food,Beverage filling and liquid transfer.
  • Can be used for washing car and conditioner.

FEATURES

  • Long life, no leak
  • Built thermal protector
  • Self priming, fully automatic, easy installation
  • Special valve for liquid input and output
  • Numerous fittings options for greater mounting flexibility.

SPECIFICATIONS

  • Pump design: 2 chamber diaphragm
  • Max. flow: 1.34GPM(5.1L/min)
  • Port size: 3/8''(9.5mm)Hose Barb
  • Pressure max: 110psi
  • Diaphragm materials: Santoprene
  • Check valve made:EPDM or Viton
  • Voltage:12v or 24v dc
  • Liquid temp: 140 °F(60°C) Maximum
  • Body material: Cast Iron
  • Spring materials:Stainless Steel

THECHNICAL DATA

Model

Volts(V)

Flow Rate(LPM)

Pressure Off(PSI)

Amp Draw(A)

KDP-3202

12

5.1

80

4.5

KDP-3402

24

5.1

80

2.8

KDP-3203

12

5.1

100

5

KDP-3403

24

5.1

100

3
KDP-3208 12 6.3 135 8.3
KDP-3408 24 6.3 135 4.5
KDP-3210 12 6.3 150 10
KDP-3410 24 6.3 150 5.5

FLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washer

FLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washer

FLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washerFLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washerFLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washerFLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washerFLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washerFLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washer

CHEMICAL RESISTANCE

Chemical Resistance Code Max Temperature Resistance Code

A —— Excellent

B —— Good

C —— Ordinary

× —— Unacceptable

－ —— Unusable

1 —— 20℃(68F)

2 —— 40℃(104F)

3 —— 60℃(140F)

4 —— 80℃(176F)

5 —— 100℃(212F)

6 —— 120℃(248F)
CHEMICAL MATERIAL
PP PTFE FKM NBR EPDM 95 Ceramic
Sulfuric Acid 0-10% A4 A6 A6 B2 A4 A5
10-75% A3 A6 A4 X A3 A5
75-100% B2 A4 A4 － B2 A5
Nitric Acid 10% A3 A5 A5 X A2 A5
30% A2 A6 A6 X A2 A5
50% B2 A3 A1 X X A5
Hydrochloric Acid 0-25% A4 A6 A3 B1 C3 A5
25-40% A4 A6 A2 X C2 A5
Hydrofluoric Acid 10% B2 A6 A3 X A3 －
30% C2 A6 A4 － B3 －
60% X A6 A4 － C2 －
Acetic Acid 20% A2 A6 B1 B2 A2 A5
80% B1 A6 X － － A5
Sodium Hydroxide 20% A3 A6 B1 B2 A3 －
50% A3 A6 X B1 A4 －
Bromine Water C1 A3 A2 － X A1
Ethyl Alcohol A2 A3 A3 X B3 A3
Ketone A2 A6 X － B2 A3
Freon 12 X A6 A1 X B1 A4
Aluminum Chloride A4 A6 A5 B4 A4 A4
Ammonia Liquid A1 A6 C1 B4 B3 A3
Aqua Regia C2 A5 B2 － C2 A4
Formaldehyde A4 A6 A4 X A4 A4
Gasoline X A6 B3 B3 X A4
Kerosene A1 A6 A1 B1 X A4
Methyl Alcohol A3 A6 B2 B4 A3 A5
Toluene C1 A4 B1 － X A5
Trichloroethylene C1 A6 A1 － X A4
Xylene X A6 B1 － X A5
Nitric Acid Anhydrous C1 A3 A1 － X A5
Oleum X A6 A4 － X A5
Potassium Hydroxide A4 A6 B1 C2 A5 －

USAGE SCOPE

Widely used in general industrial equipment, medical equipment, chemical equipment, agricultural (lawns and gardens), tourist vehicles, special vehicles, ships, beverage, vehicle cleaning, carpet cleaning, floor cleaning, water purification and water treatment equipment.
1. Production of agricultural use electric sprayer, pressure sprayer can also be hand modified electric sprayer (pressure sprayer in hand directly on the micro-pumps, adding a battery or hand lamp can be).
2. Solve vehicles, ships, yachts, boats, etc. in use diet, wash, shower, toilet, wash water.
3. Food and beverage processing and handling equipment, to achieve the transfer of liquid food, distribution, filling and so on.
4. Domestic water supply. For example, water-saving toilet, water-saving toilet, electric toilet, pressurized water system.
5. Solar energy industry.
6. Water purification industry. For example, purification equipment, water treatment equipment, drinking fountains, water machines. For towel disposal, drinking fountains, Coke machines, juice machines, dishwashers, disinfection machines, solar bonsai, car washing and other manufacturers supporting the glass.
7. Other liquid transfer needs, as well as measurement of spray equipment and systems. For example, garbage trucks, water truck, carpet cleaning equipment, floor cleaning equipment, cleaning equipment, vehicles, road construction equipment, medical equipment, chemical equipment, chemical equipment, disinfection equipment, cooling systems, pressurization systems.
