BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
Specifications
Brand Name :
BRITEC
Model Number :
BR-60 1P+1
Certification :
TUV/CB/CE/ROHS
Place of Origin :
China
MOQ :
10 Piece/Pieces
Payment Terms :
L/C, D/A, T/T, Western Union
Supply Ability :
50000 Piece/Pieces Month
Delivery Time :
Shipped in 15 days after payment
Packaging Details :
EXPORT PACKING
Item Name :
surge protection device spd
Model Numbers :
BR-60 1P+1
Protection Class :
IP20
Packing unit :
1 pcs
Type :
T2
Certificate :
TUV/CE,CB,IEC etc
Rated Voltage :
275V
Nominal discharge :
30kA
MOQ :
10PCS
Waveform :
8/20
Description

surge arrestor single phase surge protection device spd manufacture

Type 2 surge protectors are designed to be installed at the entrance of the installation, in the main switchboard, or close to sensitive terminals, on installations without LPS (lightning rods). These protectors are tested following the Class Ill test from IEC6 1643-11 or EN6 1643-11 standards and based on 8/20 us impulse current

Surge arrester, type 2

• Complete unit consisting of upper part and base, pre-mounted and ready for connection

• Plug-in upper part; upper part can be separated from base without tools

• Incl. thermal and dynamic cut-off unit

spd manufacture Technology characteristic:

BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection

BR-60 1P+1
Max. continuous operating a.c. voltage Uc(L-N/N-PE) 275V/255V (50/60Hz)
Nominal discharge current (8/20us) In(L-N/N-PE) 30kA/30kA
Maximum discharge current (8/20us) Imax(L-N/N-PE) 60kA/60kA
Voltage protection level Up(L-N/N-PE) ≤1.6kV/≤1.5kV
Response time tA ≤25ns
Max. backup fuse 125A
Operating temperature range Tu -40℃—80℃
Cross-section area (Min.) 4mm2
Cross-section area (Max.) 35mm2
For mounting on 35mm Din rail
Enclosure material Thermoplastic UL94-V0
Test standards

IEC 61643-11, EN 61643-11


spd manufacture Dimension:

BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection

spd manufacture Application:

· For electrical installations.

· Suitable for lightning protection of power supply system in areas with high risk of lightning strike.

· Can handle lightning currents and protect sensitive electronic equipment.

· Application-optimized and prewired combined lightning current.

spd manufacture Certificate:

CB, CE, TUV,RoHS Certificate

BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
Company information:

Wenzhou Britec Electric Co., Ltd. established in the year of 2003 and located in Yueqing, Zhejiang, China. Our company specialized in research and development of surge protection devices.The series of surge protection device Type 1 and Type 2 and Type 3, BR PV and SPDs for Data offer the market with a new choice of high quality surge arresters. We have 18 years of experience in the research & development and production of the surge protection field and provide 5 years warranty.
.

BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
Production line:
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
Laboratory equipment:
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
Shipping:
BR-60 Spd Surge Protective surge Arrester Device 1P+1 Single Phase lightning protection
FAQ:

Q1: Selection of surge protector

Al: The grading of the surge protector (commonly known as lightning protection) Is assessed according to the IEC61024 subdivision lightning protection theory, which is installed at the junction of the partition. Technical requirements and functions differ. The first-stage lightning protection device is installed between the 0-1 zone, high for the flow requirement, the minimum requirement of EN 61643-11 / IEC 61643-11 is 25 ka (10/350), and the second and third levels are installed between the 1-2 and 2-3 zones, mainly to suppress the overvoltage.

Q2: Are you a lightning surge protectors factory or lightning surge protectors trading company?

A2: We are a lightning surge protectors manufacturer.

Q3: Warranty and services:

A3:1. Warranty 5 years

2. lightning surge protectors products and accessories have been tested 3 times before ship out.

3. We own the best after-sale service team, if any problem happens, our team will do our best to solve it for you.

Q4: How can I get some lightning surge protectors samples?

A4: We are honored to offer you lightning surge protectors samples, pis contact our staff, and leave detailed contact information, we promise to keep your information confidential.

Q5: Is the sample available and free?

A5: Sample is available, but the sample cost should be payable by you. The cost of the sample will be refunded after further order.
