BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
Specifications
Brand Name :
BRITEC
Model Number :
BR-25M 3P+1NPE
Certification :
TUV/CB/CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
1 Piece/Pieces
Payment Terms :
L/C, D/A, T/T, Western Union
Supply Ability :
50000 Piece/Pieces Month
Delivery Time :
Shipped in 15 days after payment
Packaging Details :
EXPORT PACKING
Item Name :
25kA low voltage surge arrestor device
Model Numbers :
BR-25M 3P+1NPE
EN type :
T1+T2
Configuration :
3+1
Place of Origin :
Wenzhou
Response time :
25ns
MOQ :
3 PCS
Description

T1+T2 surge arrester 25kA low voltage surge arrestor device​

T1+T2 surge arrester Features:

Iimp by pole: 25 kA
Single, 3 or 3-Phase+Neutral AC network
230/400 V, 120/208 V and 690 V AC network
All AC system types
Common mode protection (CT1 configuration) or Common and Differential mode protection (CT2 configuration)

T1+T2 surge arrester​ Technology characteristic:

BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd

BR-25M 3P+1NPE
Max. continuous operating a.c. voltage Uc 275V
Lightning impulse current (10/350us) Iimp 25kA
Nominal discharge current (8/20us) In 25kA
Maximum discharge current (8/20us) Imax 100kA
Voltage protection level Up ≤1.3kV
Response time tA ≤25ns
Max. backup fuse 315A
Operating temperature range Tu -40℃—80℃
Cross-section area (Min.) 4mm2
Cross-section area (Max.) 35mm2
For mounting on 35mm Din rail
Enclosure material Thermoplastic UL94-V0
Test standards

IEC 61643-11, EN 61643-11


T1+T2 surge arrester​ Dimension:

BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd

T1+T2 surge arrester Application:

Application-optimized and prewired combined lightning current.
• Particularly useful in a high lightning density area where the risk of heavy surge current or even direct strike is high (e.g.: buildings equipped with lightning rods).

T1+T2 surge arrester​ Certificate:

CB, CE, TUV,RoHS Certificate:

BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
Company information:

Wenzhou Britec Electric Co., Ltd. established in the year of 2003 and located in Yueqing, Zhejiang, China. Our company specialized in research and development of surge protection devices.The series of surge protection device Type 1 and Type 2 and Type 3, BR PV and SPDs for Data offer the market with a new choice of high quality surge arresters. We have 18 years of experience in the research & development and production of the surge protection field and provide 5 years warranty.
.

BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
Production line:
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
Laboratory equipment:
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
Shipping:
BR-25M 3P+1NPE 25kA T1+T2 Surge Arrester B+C Low Voltage 3 Phase type 1 AC spd
FAQ:

Q: Are you trading company or manufacturer?

A: We are professional manufacturer specialized in orthopedic and sport products. And we trade our products with our clients directly.

Q: Can you do OEM and ODM?

A: Yes, OEM and ODM are both acceptable. The material, color, style can customize, the basic quantity we will advise after we discuss.

Q: Can we use our own logo?

A: Yes, we can print your private logo according to your request.

Q: What’s your MOQ?

A: If we have the products in stock, it will be no MOQ. If we need to produce, we can discuss the MOQ according to customer’s exact situation.

Q: Which payment form you can accept?
A: T/T, Western Union, PayPal etc. We accept any convenient and swift payment term.
