Shadowless 760760 LED Operating Theatre Lamp Medical Lighting Equipment
Shadowless 760760 LED Operating Theatre Lamp Medical Lighting Equipment
Shadowless 760760 LED Operating Theatre Lamp Medical Lighting Equipment
Shadowless 760760 LED Operating Theatre Lamp Medical Lighting Equipment
Shadowless 760760 LED Operating Theatre Lamp Medical Lighting Equipment
Shadowless 760760 LED Operating Theatre Lamp Medical Lighting Equipment
Shadowless 760760 LED Operating Theatre Lamp Medical Lighting Equipment
Shadowless 760760 LED Operating Theatre Lamp Medical Lighting Equipment
Specifications
Brand Name :
HFMED
Model Number :
760760 LED Operating Lamp (Adjust Color Temperature)
Certification :
CE,ISO,SGS
Place of Origin :
Shanghai,China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, Western Union, T/T, D/A, D/P, MoneyGram
Supply Ability :
500 sets/month
Delivery Time :
5~7 days after payment received
Packaging Details :
carton or wooden case
Illuminance :
160,000 Lux
Color temperature :
3800±200K; 4400±200K ;5000±200K
Color reduction index(Ra) :
96
Illuminance depth :
1150mm
Total irradiance :
510W/m²
Size of light field :
180-260mm
Endo Bulb :
2 Pcs
Endo Illuminance :
3000 Lux
lamp head diameter :
760mm
Rated power of bulb :
3.2V/1W
Service life of illuminant :
50,000h
Power supply voltage :
AC110-240v,50/60Hz
Lowest height of installation :
2900mm
Total power consumption :
200W
Total LED bulb quantity :
262 pcs
Warranty :
2 years
Delivery :
5~7 days after payment received
Description

LED Operating Room Lights Surgical Lamp , Medical Lighting Equipment Adjust Color Temperature

Shadowless effect

Patented configuring design,Lighting is Configured with two similar color temperature, is realized by computer- simulating, to provide shadowless effect and avoid eye fatigue of surgeons.

Control Panel

Imported DC stepping motor, adjust the luminance and color temperature by touching the panel.

Focal distance is adjusted by turning the handle in middle of lamp head.

Cold light effect

Adopt imported Osram LED beads as light source, with low infrared ray, to provide perfect cold light effect.

Color temperature


4500K color temmperature, approaches the natural sunlight, ensure the surgeon to identify the color of vascular tissue and nerve tract clearly and accurately.

Color rendering index is over 95, to show the most real color of organs and tissues

LED SERIES

SHADOW LESS OPERATING LAMP

The key advantage of the pedal head design is that it can largely reduce the disturbance of the air laminar flow in the operating room. The streamline lamp body and the small size petals conform to the air flows principle, it can meet the clean operating room standards very well.The ceiling mounting installation can save the space, the double lamp heads can provide a comparable lighting effect to the doctor. The LED light source has a long lifetime of more than 50000h.

Uniform,homogeneous lighting in surface and deep cavity procedures thanks to 760-LED´s innovative shadow control. Our ergonomic, sterile operating concept allows for the simple and flexible control of all functions by the surgical team. Almost unlimited LED life expectancy delivers tremendous product reliability and investment protection. Environmentally proactive: low power consumption and durable LEDs minimize the impact on our precious resources.

Shadowless 760760 LED Operating Theatre Lamp Medical Lighting Equipment

Type 760760(LED) Shadowless Operating lamp
Material Aluminum Alloy
Illuminance(Lux) ≥160,000
Colour temperature(k) 3800±200K; 4400±200K ;5000±200K
Colour rendering index(Ra) 96
Total irradiance (W/m2) 510/510
Size of light field (mm) 180-260
Illuminant Life ≥50000h
Power supply voltage AC110V-240V(50HZ-60HZ)
Total power consumption(W) 200
Total LED bulb quantity(pcs) 262
Lowest height of installation(mm) 2900mm
Endo Mode 3000k
Warranty 2 years

Packaging & Delivery

2 piece in a carton: 113*109*45cm
GW/NW: 36kg/27kg
1 piece in a wooden case 122*42*85cm
GW:/NW: 81kg/70kg

FAQ

Q1. Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit for led light order?

A: Low MOQ, 1 pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
