Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER
Specifications
Brand Name :
FOIF
Model Number :
A80
Place of Origin :
China
MOQ :
1 piece
Price :
$4,200.00
Payment Terms :
L/C, T/T
Supply Ability :
1 ~ 30 day
Delivery Time :
30 work day
Product name :
RTK receiver FOIF A80 Base and Rover
Customized support :
OEM
Channel :
800 Channels
Transmitting speed :
9.6Kbps, 19.2Kbps
Transmitting power :
0.5W, 1W, 2W adjustable
Frequency range :
410 - 470MHz
Working range :
5km typical, 8~10km optimal
GPS :
L1C/A,L1C,L1P,L2C,L2P,L5
Description

Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER

Overview

Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER

Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER

Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVERSurveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVERSurveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVERSurveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER

Number of channels: 800
Satellite tracking :
GPS: L1C/A,L1C,L1P,L2C,L2P,L5 ;
GLONASS : G1P1,G1OC,G2OC,G2P2,G3OC
BDS: B1I, B2I, B3I, B1C, B2a, B2b, ACEBOC
Galileo: E1BC, E5a, E5b, ALTBOC, E6
QZSS: L1C/A, L1C, L2C, L5, LEX ;
SBAS: L1, L5 ;
IRNSS: L5;
L-band
Update rate: 50Hz
Accuracy
Static measurement: H: ±(2.5+0.5×10-6D)mm; V: ±(5+0.5×10-6D)mm
RTK measurement: H: ±(8+1×10-6D)mm; V: ±(15+1×10-6D)mm
Tilt compensation: 60 degrees, accuracy 2cm
Electro-foam: Allow
Source parameters
Battery type: Rechargeable battery, non-removable, 7.2V/13600mAh, 97.92Wh
Measurement time: 15 hours of static measurement and 12 hours of dynamic measurement
External power supply: Use of an external charging cable DC 12-28V, with anti-shock
System settings
Operating System: Linux 4.1.18
Memory: 512MB LPDDR3,32G EMMC
: 2.1+EDR /4.0 Dual, (Class 2)
WIFI: 802.11 b/g/n
Network Modem: 4G; LTE FDD; LTE TDD; TDSCDMA; WCDMA; CDMA 1x/EVDO; GSM
SIM card type: Nano, Side, Flip SIM card
Voice: TTS Voice Broadcast
WebUI: Helps manage status, mode, firmware update and data download
Radio in
Radio type: UHF TX & RX radio
Frequency: 410-470MHz
Transmitter power: 7w
Range: 12KM
Protocols: SATEL/ TrimTalk/TRIMMARK3/PCC-GMSK/GEOTALK/TT450S/South/ HiTarget, etc.
External radio connection: 5 Pin port
Physical parameters
Dimensions: 154 mm × 154 mm × 76 mm
Display: Color touch screen
Communication ports: 1 TNC antenna port, 1 5-pin port (power+rs232), 1 7-pin port (usb+RS232)
Button: 1 single power button
Environmental parameters
Operating temperature: -30℃ ~ +60℃
Storage temperature: -40℃ ~ +80℃
Shock and impact resistant: Drop from a 2m pole or free fall from a height of 1.2m onto the concrete floor.
Dust and water resistant: IP68
Resistance to humidity: 100%.

If you want to know more about our products, please consult us!

Our Services and Advantages

Services

1.Any inquiries will be replied within 12 hours.
2.All our products have one year warranty, And we sure the products will be free for maintenance within warranty period.
3.All products will have been strictly quality checked in factory before sending out.

Certifications

Surveying Instrument GPS RTK Base and Rover FOIF A80 800 Channels GNSS GPSS RTK RECEIVER

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
