Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover
Specifications
Brand Name :
SOUTH
Model Number :
GALAXY G1
Place of Origin :
China
MOQ :
1 piece
Price :
$5,300.00 - $5,500.00
Payment Terms :
L/C, T/T
Supply Ability :
1 ~ 30 day
Delivery Time :
30 work day
Product name :
RTK receiver SOUTH GALAXY G1 Base and Rover
Customized support :
OEM, ODM, OBM
Channel :
220(standard), 965(optional), 555(optional)
Protocol :
GeoTalk,SATEL,PCC-GMSK,TrimTalk,TrimMark
Static accuracy :
Horizontal: ± 2.5mm + 1ppm, Vertical: ± 5mm + 0ppm
RTK accuracy :
Horizontal: ± 8mm + 1ppm, Vertical: ± 15mm + 0ppm
SBAS :
L1 CA, L4
GALILEO :
E3BC, 35A, E4B
Description

Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover

Innovative structure design
Powerful new bluetooth module
Tilt survey
Electronic bubble correct
Full satellite constellations support
Intelligent and open platform
Cloud service
Advanced data-link module
NFC function

Features:

SOUTH Galaxy G1, new generation integrated RTK system with smaller size and innovative design, leads the direction of new generation RTK with excellent performance, provides high-efficiency and intelligent surveying experience to customers. It isn't simply smaller, it's better in everywhere.

Overview

Model
G1
GNSS performance
Channels
220(standard), 965(optional), 555(optional)
GPS
L1C/A, L1C, L2E, L2C, L5
GLONASS
L1C/A, L1P, L2C/A, L2P, L3
BDS
B1, B2, B3
GALILEO
E1, E5a, E5b, Alt-BOC, E6
SBAS
L1 C/A, L5
QZSS, WAAS, MSAS, EGNOS, GAGAN
L-Band
--
Positioning output rate
1Hz, 2Hz, 5Hz, 10Hz, 20Hz & 50Hz (depends on installed option)
Initialization time
<10s
Initialization reliability
>99.99%
Positioning precision
Static surveying
Horizontal: 2.5mm+0.5ppm; Vertical: 5mm+0.5ppm
Code differential positioning
Horizontal: 25cm+1ppm; Vertical: 50cm+1ppm
Real-time kinematic surveying
Horizontal: 8mm+1ppm; Vertical: 15mm+1ppm
RTX
--
SBAS positioning
Typically<5m 3DRMS
xFill
IMU tilt angle
Single positioning
--
User interaction
Operaing system
Linux
Buttons
Single button operation
LCD
--
Indicators
3 indicate lights
Web UI
Freely to configure and monitor the receiver by accessing to the web server via Wi-Fi and USB
Voice guide
iVoice intelligent voice technology provides status and voice guide, Supports Chinese, English, Korean, Russian, Portuguese,
Spanish, Turkish and user define
Secondary development
--
Data cloud service
--
Hardware performance
Dimension
129mm (Diameter) x 112mm (Height)
Weight
1kg (battery included)
Material
Magnesium aluminum alloy shell
Operating temperature
-45°C ~ +60°C
Storag temperature
-55°C ~ +85°C
Humidity
100% Non-condensing
Waterproof/Dustproof
IP68 standard, protected from long time immersion to depth of 1m, and fully protected against blowing dust
Shock and vibration
Withstand 2 meters drop onto the cement ground naturally
Power Supply
9-25V DC, overvoltage protection
Battery
Rechargeable, removable Lithium-ion battery, 7.4V 3400mAh/per
Battery solution
4 standard batteries power package (optional)
Battery life
--
Communications
I/O port
5-PIN LEMO port, 7-PIN USB port (with OTG); 1 TNC radio antenna interface, SIM card slot
Wireless modem
Built-in radio, 1W/2W/3W switchable, typically work range can be 8KM, radio and internet repeater switchable
Frequency Range
410-470MHz
Communication Protocol
TrimTalk, SOUTH, SOUTH+, SOUTHx, huace, ZHD, Satel
Cellular Mobile Network
TDD-LTE/FDD-LTE 4G network modem
Double Module Bluetooth
BLEBluetooth 4.0 standard, Bluetooth 2.1 + EDR standard
NFC Communication
Realizing close range (shorter than 10cm) automatic pair between receiver and controller
External Devices
--
WIFI
Standard
802.11 b/g standard
WIFI Hotspot
The WIFI hotspot allows any mobile terminal to connect and access to the internal webserver for the control and moditor receiver
WIFI data link
To work as the datalink that receiver is able to broadcast and receive differential data via WIFI
Data storage/ Transmission
Data Storage
8GB SSD internal storage, supports external USB storage and automatical cycle storage, changeable record interval, up to 50Hz raw
data collection
Data Transmission
USB data transmission, supporting FTP/HTTP data download
Data Format
Static data format: STH, Rinex2.x and Rinex3.x etc
Differential data format: CMR+, SCMRx, RTCM 2.1, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2
GPS output data format: NMEA 0183, PJK plane coordinates, binary code, Trimble GSOF
Network model support: VRS, FKP, MAC, supporting NTRIP protocol
Inertial sensing system
Tilt survey
Optional, built-in tilt compensator, correcting coordinates automatically according to the tilt direction and angle of the
centering rod
Electronic bubble
Optional, controller software display electronic bubble, checking leveling status of the centering rod real time
Thermometer
Optional, built-in thermometer sensors, adopting intelligent temperature control tech nology, monitoring and adjusting the
receiver temperature in real time

Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover

Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover

Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover

Packing & Delivery

Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover

Certifications

Land Measurement SOUTH GALAXY G1 RTK GPS Receiver GNSS RTK Base And Rover

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
