Specifications
Brand Name :
SEOP
Model Number :
DEL-2B
Place of Origin :
China
MOQ :
1 set
Price :
＄550
Payment Terms :
T/T, L/C
Delivery Time :
30 work day
Product Name :
laser Electronic Theodolites DEL-2B
Warranty :
1 year
Image :
Erect
Magnification :
30X
Effective Aperture :
45mm
laser class :
Class II
wavelength :
635±20nm
Center spot diameter :
≤5cm/1000m
Display :
LCD Display
Measure Time :
Continuous: 0.35s, Single 1.5s
Resolving Power :
3''
Minimum Focus Range :
1.4m
Description

Simple operation 2'' Angle Accuracy Eter Visible Laser Theodolite Clearness LCD Screen Power Supply Lasting up-down laser

Product Description

Electronic tilt sensor compensation
Corrects tilt errors in real time, with an angular accuracy of 2‘’.
2 seconds of angle measurement High accuracy
Improved instrument stability and measurement accuracy for vertical angle measurements
Lasting battery life
1650AH high capacity lithium battery, out of the measurement, do not worry about power failure.
Co-focal coaxial visible dual laser
Save time and energy
Visible laser point is directly aligned with the target point
Lower laser in the alignment axis
Laser alignment
More intuitive solution to alignment problems

Telescope
Erect
Magnification
30x
Effective Aperture
45mm
Resolving Power
3″
Field of view
1°30′
Minimum Focus Range
1.4m
Multiple Constant
100
Additive Constant
0
Stadia Accuracy
≤0.40%/L
Tube Length
45mm
Angle Measurement
Measuring Method
Absolute Encoding
Dia. of Encoder Disk
79mm
Minimum Reading
1″
Accuracy
2″
Detection Method
Horizontal: Dual, Vertical: Dual
Compensator
Type
Single Axis
Working Range
±3′
Accuracy
±3″
Laser Plummet
Accuracy
±1.5mm(@1.5m)
Spot Diameter
±2.5mm(@1.5m)
Wave Length
635±20mm
Display Unit
Type
2.6 Inch,160*96 LCD Screen
Power Supply
Battery
7.4V Lithium Rechargeable Battery
Environment
Working Range
﹣20℃ ～﹢50℃
Dimension
Size
165 × 160 × 340 (mm)
Weight
4.7kg
