SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm
SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm
SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm
SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm
SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm
SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm
SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm
SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm
Specifications
Brand Name :
GUOMAT
Model Number :
SZ 35-11
Certification :
ISO/TS16949:2009
Place of Origin :
Guangdong , China
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal and Others
Supply Ability :
10000 pcs / week
Delivery Time :
2 - 8 Work Days
Packaging Details :
Strong Carton Box or as Customer's Require
Main Material :
Steel Rubber
Position :
Seat
Net Weight :
0.4 kg
Other Name :
Sleeve Type Air Spring
OEM :
SZ 35-11
Status :
Brand New
Spring Type :
Gas Filled
Description

SZ 35-11 CONTI Sleeve Type Suspension Air Spring Design height H: Recommended 150mm


Cross OEM Of this item:

GUOMAT:G3037

CONTITECH SZ 35-11

Min. pressure:0,9 [bar]

Return force to min. height:≤ 400 N.

Overall weight with clamped plates:0.4 kg.

Vibration isolation - dynamic characteristic values
Design height H: recommended 150mm, lateral guidance necessary

Pneumatic application - static characteristic values Force F [kN]

With G 3/8 air inlet

Order No.2687 001 000



Descripition and Specifications Of SZ 35-11:

Package Size: 3.6*3.6*5(in.) Package Size: 92mm*92mm*127mm
Net Weight: 0.4 KG Lower Plate OD : 50 MM
Gross Weight: 0.8 KG Extended Height : 205 MM
Upper Plate OD : 76.5 MM air inlet G 3/8
stud M30*1.5 Installation space needed 100 mm


GUOMAT air spring production of the air spring has the following advantages:

1, product quality, Thailand import natural rubber, the core technology in Germany
2, With the same price on the market, GUOMAT optimal quality. With the same quality of products, GUOMAT has lowest price.
3, cars, trucks, buses and industrial air spring has production, fully meet the customers' different requirements.
4, GUOMAT spell price, not only do the brand.
5, more than 10 years of production technology, products cover all over the world.
6, have dealers around the world, the first response to all customer requirements.


Packing List of GUOMAT:G3037 Air Spring :

Description PCS Net Weight Package Weight Gross Weight Length
(cm)		 Width
(cm)		 Height
(cm)		 Measurememt
(cbm)
Air Suspension 1 0.4 kg 0.4 kg 0.8 kg 12 9.2 9.2 0.00102
Shipping Terms By DHL/UPS/FEDEX/TNT/AIRWAY/LCL/FCL or By Sea. It will take about 1 to 4 working days to reach By Express.
Payment Terms T/T, Western Union,Paypal and Others

Other kinds GUOMAT can produce:

SK37-6;SK37 6;SK376

SK37-8;SK37 8;SK378

SK37-10;SK37 10;SK3710

SZ50-11;SZ50 11;SZ5011

SZ70-11;SZ70 11;SZ7011

SZ 100-11;SZ 100-11;SZ 10011

SZ 140-11;SZ 140-11;SZ 14011


SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm

SZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mmSZ 35-11 CONTI Sleeve Type Suspension Air Spring Height Recommended 150mm
