GOODYEAR 1R14-781 / 1R14781 Truck Air Springs Flexmember 566-28-3-504 For BPW 36-1
GOODYEAR 1R14-781 / 1R14781 Truck Air Springs Flexmember 566-28-3-504 For BPW 36-1
GOODYEAR 1R14-781 / 1R14781 Truck Air Springs Flexmember 566-28-3-504 For BPW 36-1
GOODYEAR 1R14-781 / 1R14781 Truck Air Springs Flexmember 566-28-3-504 For BPW 36-1
GOODYEAR 1R14-781 / 1R14781 Truck Air Springs Flexmember 566-28-3-504 For BPW 36-1
GOODYEAR 1R14-781 / 1R14781 Truck Air Springs Flexmember 566-28-3-504 For BPW 36-1
GOODYEAR 1R14-781 / 1R14781 Truck Air Springs Flexmember 566-28-3-504 For BPW 36-1
GOODYEAR 1R14-781 / 1R14781 Truck Air Springs Flexmember 566-28-3-504 For BPW 36-1
Specifications
Brand Name :
GUOMAT
Model Number :
1R14-781 / 1R14 781 / 1R14781
Certification :
ISO/TS16949
Place of Origin :
Guangdong , China
MOQ :
1pc
Price :
$59-159/pc
Payment Terms :
T/T, Western Union,paypal or others
Supply Ability :
1000pcs/week
Delivery Time :
2-8 work days
Packaging Details :
strong carton box or as customer's need
Material :
Rubber Bellows ,Steel Piston
GOODYEAR :
1R14-781 / 1R14 781 / 1R14781
Other Name :
BPW Air Spring Shock
CONTITECH :
942 MB**CA / 942MB / 942 MB
BPW :
05.429.41.71.1
Airtech :
130802 / 3942-01 C
Description

Air Spring GOODYEAR 1R14-781 / 1R14 781 / 1R14781 Flexmember 566-28-3-504 For BPW 36-1

OEM Cross Number:

GUOAMT NO.:1T942MB CA1

CONTITECH 942 MB**CA / 942MB / 942 MB
GOODYEAR 1R14-781 / 1R14 781 / 1R14781
Flexmember Part number: 566-28-3-504
Airtech 130802 / 3942-01 C

OEM Suspension Supplier Number:

BPW BPW 36-1
BPW 05.429.41.71.1
BPW 05.429.41.69.0

The Composition Of Reversible Sleeve Models Rolling Air Spring Element Has The Following Aspects-GUOMAT

❶ screw bolt / Stud - Produced as a permanent part of the Cover Plate assembly for maximum strength and durability. It is used to attach the air spring to the vehicle’s suspension system.

❷ Combined link rod / Combo Stud – Used as the dual purpose of installing the air spring to the suspension system and providing the air inflation.

❸ Cover Plate - Curled up to more durable bellows design and the largest quality control in the factory. Allows 100% of the leak test before shipment.

❹Rubber Bellows - Air Bellows includes four layers of materials: an inner layer, two layer cord - reinforced fabrics, and a cover. Construction of a natural rubber provides – 65F functional properties.

❺ Bumper block / Buffer block - Solid rubber or engineering plastic device designed to prevent major damage to the vehicle or suspension in the event of a sudden loss of air pressure in the spring.

❻ Bottom Piston - Provides a low installation of air spring. To control the pressure in a changing under the load characteristics of spring.

❼Piston Bolt - Connecting the piston to the bellows. Sometimes extensions as an additional vehicle suspension spring.

GOODYEAR 1R14-781 / 1R14781 Truck Air Springs Flexmember 566-28-3-504 For BPW 36-1
