2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow
2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow
2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow
2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow
2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow
2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow
2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow
2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow
Specifications
Brand Name :
GUOMAT
Model Number :
W01-358-7325/26
Certification :
ISO/TS16949:2009
Place of Origin :
GuangDong, China
MOQ :
6pcs
Price :
$59.9-69.9/pc
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
1000pcs/week
Delivery Time :
2-8 work days
Packaging Details :
Strong Carton Box Or As Customers Need
Product Type :
Air Suspension Spring
Material :
Rubber Bellow and Aluminum Cover
Warranty :
1 Year Warranty
Quality :
100 % Tested
Air Fitting :
Center of Cover Plate
Type :
Double Convoluted Type
Plate Dia. :
135mm
Brand :
GUOMAT/Neutral
Description

FD120-20 509 Contitech Parts Rubber Air Bellow 2B8-550/153 Goodyear Helper Springs

Product Description

Product Name: New Comfortable Pneumatic Spring

Material: Steel + Rubber

Warranty: 12 Months

Color: Black
Place of Origin: Guangzhou,China
Certification: ISO/TS16949:2009
Package: Carton
Quality: High-Quality
Application: Industrial Machine/Car Air Suspension

Cross References

Firestone

W01-358-7325/26

Contitech

FD 120-20 509

Firestone

W013587325/26

Contitech

FD120-20 509

Firestone

W01 358 7325/26

Contitech

FD 120-20509

Goodyear

2B8-550/153

Goodyear

579923530

Goodyear

2B 8-550/153

Goodyear

579-92-3-530

Triangle

6392

Triangle

4509

Original Parts

American Carrier

8003-006

Mac-k truck

227QS-32

E.R.F

1398567

Mac-k truck

57QK1113

Sauer

P10-754

SAF Holland

57007325

Ridewell

1003587325C

Watson&Chalin

AS-0030

Hendrickson

S-14395/NA1821

Terberg

21065660

Technical Data

1. Top Cover Plate Diameter: 135mm

2. Bottom Cover Plate Diameter: 135mm

3. Distance Between Threaded Holes of the Top Cover Plate: 70mm

4. Distance Between Threaded Holes of the Bottom Cover Plate: 70mm

5. The Rubber Bellow Natural Diameter: 185mm

6. The Natural Height: 196mm

Application

  • GATE VALVE OPERATOR
  • GLUING PRESS
  • WEB TENSIONING DEVICE
  • DIE STRIPPER
  • KNIFE SPRING ACTUATOR
  • QUENCH TANK ACTUATOR
  • PAPER SIZING PRESS
  • PICKLING TANK ACTUATOR
  • QUICK LOCK DEVICE
  • PRESSURE ROLL FOR CALENDER
  • MISSILE ASSEMBLY FIXTURE
  • CORE STRAIGHTENER
  • BELT TAKE-UP
  • ROLLER FRICTION BRAKE
  • PIPE INDEXING THREADING
  • OSCILLATING DOCTOR FOR PAPER CALENDER ROLL
  • FORMING PRESS
  • CABLE TENSIONING DEVICE
  • BAG FLATTENER
  • TORSIONAL FRICTION BRAKE

Firestone Double Convoluted Air Spring

Firestone Style Firestone Style
W01-M58-6160 25 W01-M58-6400 224
W01-358-0030 25 W01-358-5101 224
W01-358-0025 25 W01-358-3407 224
W01-M58-6105 255-1.5 W01-M58-6353 26
W01-358-6833 255-1.5 W01-M58-6387 26
W01-358-0048 255-1.5 W01-M58-6988 26
W01-358-0142 26 W01-M58-6187 274
W01-M58-6186 274 W01-M58-6188 274
W01-M58-6990 274 W01-M58-6185 274
W01-358-0297 274 W01-M58-6192 202
W01-M58-6190 202 W01-M58-6183 20-2
W01-M58-6194 20-2 W01-M58-6880 20-2

2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow 2B8-550/153 Goodyear Helper Springs FD120-20 509 Contitech Parts Rubber Air Bellow
