S400-3R Yokohama Rubber Air Spring Cross GUOMAT F-400-3 For Paper & Pulp Mill Equipment
S400-3R Yokohama Rubber Air Spring Cross GUOMAT F-400-3 For Paper & Pulp Mill Equipment
S400-3R Yokohama Rubber Air Spring Cross GUOMAT F-400-3 For Paper & Pulp Mill Equipment
S400-3R Yokohama Rubber Air Spring Cross GUOMAT F-400-3 For Paper & Pulp Mill Equipment
S400-3R Yokohama Rubber Air Spring Cross GUOMAT F-400-3 For Paper & Pulp Mill Equipment
S400-3R Yokohama Rubber Air Spring Cross GUOMAT F-400-3 For Paper & Pulp Mill Equipment
Specifications
Brand Name :
GUOMAT
Model Number :
F-400-3
Certification :
ISO/TS16949:2009
Place of Origin :
Guangdong,China
MOQ :
1 pc
Price :
Negotiable
Payment Terms :
T/T, Western Union,paypal or others
Supply Ability :
1000pcs/week
Delivery Time :
2-8 work days
Packaging Details :
strong carton box or as customers need
Material :
Rubber and Steel
Yokohama :
S400-3R
GUOMAT :
F-400-3
Layer Number :
3 Convolution
Using Maximum Internal Pressure :
0.69 Mpa
Vibration Frequency :
1.8 Hz
Warranty :
12 Months
Color :
Black
Description

S400-3R Yokohama Rubber Air Spring Cross GUOMAT F-400-3 For Paper & Pulp Mill Equipment​

Description of This F-400-3 air spring

This F-400-3 punch air spring is produced by the GUOMAT factory. This air spring can use for the Product Attributes of the press machine:Such as High-Speed Punching Machine;General Punching MachinepDeep Throat Punching Machine;Turret Punching Machine.

The model of the YOKOHAMA punch air spring is S-400-3, the size is the same, they can be common.

This GUOMAT NO.F-400-3 punch air spring warranty time for one year.

Our product quality is guaranteed.

We are exported to all over the world, the customer response is very good.

Made in China air springs can be used with confidence, we are also very competitive in terms of price.

This item Detailed Parameter Table 1:

GUOMAT NO. Reference No. Hight H(mm) Commonly Maximum Stroke(mm) The Largest Diameter When Compressed(mm)
Design High(mm) Maximum High(mm) Minimum Height(mm)
F-400-3 S-400-3r 160 260 90 ±68 460

This item Detailed Parameter Table 2:

Standard Height,Internal Pressure 0.49 M pa When The General Value Using Maximum Internal Pressure (M pa) Internal Pressure (M pa)
Effective Area (Cm2) Volume(L) Load (K n) Dynamic Spring Parameters (N/Min) Vibration Frequency (Hz)
1260 19.5 61.6 834 1.8 0.69 3.9-4.9

Punch Shape:

  • Closed Punch
  • Semi-Open Punch
  • Tiltable Punch
  • Open Punch
  • Other

Slider Movement:

  • Triple Action
  • Double Action
  • Single Action
  • Other

Slider Drive Mechanism:

  • Cam Press
  • Link Press
  • Rack Press
  • Screw Press
  • Friction Press
  • Knuckle Press
  • Crankless Press
  • Crank Press
  • Other

Controlling Mode:

  • CNC
  • Artificial
  • Other

Automatic Grade:

  • Automatic
  • Semiautomatic
  • Manual

Power Source:

  • Hydraulic Pressure
  • Mechanical Drive
  • Pneumatic
  • Electric
  • Manual
  • Joint Drive

Precision:

  • High Precision
  • Normal Precision
  • Precision

Certification: ISO 9001

Condition: New

Transport Package: Cartons

Trademark: GUOMAT

Origin: Guangzhou China

Color Black

3 Storey
