YOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching Machine
YOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching Machine
YOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching Machine
YOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching Machine
YOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching Machine
YOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching Machine
YOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching Machine
YOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching Machine
Specifications
Brand Name :
GUOMAT
Model Number :
F-240-3
Certification :
ISO/TS16949:2009
Place of Origin :
GuangDong, China
MOQ :
6pcs
Price :
$299.9/pc
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
1000pcs/week
Delivery Time :
2-8 work days
Packaging Details :
Strong Carton Box Or As Customers Need
Material :
Rubber+Steel
Warranty :
One Year Warranty
Natural Outer Diameter :
285mm
Color :
Black
Number of Bellows :
Three
YOKOHAMA :
S-240-3R
Style :
Triple Convoluted
Used For :
Industrial Punching Machine
Description

YOKOHAMA S-240-3R Punching Machine Rubber Air Spring Triple Convoluted Air Lift Bag​

Product Description

GUOMAT No. F-240-3
YOKOHAMA S-240-3R
YOKOHAMA S 240 3R
YOKOHAMA S-240-3

Model Number : F-240-3

Item Name : Used for Punching Machine Rubber Air Spring

Material : Natural Rubber

Warranty : 1 Year Factory Warranty

Number of Convolution : Three- layers of Rubber

Color : Black

Mark: Can replace Yokohamas F-240-3R industrial punch equipment. Please pay attention to the size data of the product before buying. If you have any questions, please contact us at any time.

S-240-3 Technical Data Purchase Order Data

Design Height : 152 (mm)
Max Height : 232 (mm)
Min Height : 82 (mm)
Common Maximum Travel : ±60 (mm)
Compression Max Outside Diameter : 300 (mm)
Effective Area : 450(cm2)
Volume Load : 7.3 (L)
Dynamic Spring Constant : 324 (n/mm)
Natural Vibration Frequency : 1.9 (Hz)
Maximum Interal Pressure : 0.88 (Mpa)
Internal Pressure Failure : 2.9-3.9 (Mpa)

Other Type of Air Spring

Type

YOKOHAMA Number

S-600-

S-600-1

S-600-2

S-600-3

S-600-4

S-600-5

S-550-

S-550-2

S-550-3

S-500-

S-500-2

S-500-3

S-500-4

S-500-5

S-450-

S-450-5

S-450-4

S-450-3

S-450-2

S-450-1

S-400-

S-400-2

S-400-3

S-400-4

S-400-5

S-350-

S-350-1

S-350-2

S-350-3

S-350-4

S-300-

S-300-1

S-300-2

S-300-3

S-300-4

S-240-

S-240-1

S-240-2

S-240-3

S-240-4

S-220-

S-220-1

S-220-2

S-220-3

S-220-4

S-200-

S-200-2

S-200-3

S-200-4

S-160-

S-160-1

S-160-2

S-160-3

S-160-4

S-120-

S-120-2

S-120-3

S-120-4

S-100-

S-100-2

S-100-3

S-100-4

S-90-

S-90-3

What are the characteristics of the punch air spring shock absorber:


1. Excellent shock-proof and sound-absorbing performance;
2. Designed with low natural frequency value, the shockproof effect is excellent;
3. Oil-proof cap design, with oil resistance can prevent general oil corrosion;
4. It is suitable for shock equipment vibration, and the vibration of the surrounding environment affects precision equipment, and the effect is excellent.

Product Pictures

YOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching MachineYOKOHAMA S-240-3R Rubber Air Spring Triple Convoluted Air Lift Bag For Punching Machine
