Specifications
Brand Name :
GUOMAT
Model Number :
3B10X7
Certification :
ISO/TS16949, ISO9001
Place of Origin :
Guangdong, China
MOQ :
5
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, Western Union
Supply Ability :
1000PCS/Week
Delivery Time :
5-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
N.W. :
2.4 KG
Air Inlet :
1/2 NPT
Cover Plate Dia :
131 mm
Warranty :
One Year
Material :
Rubber and Iron
Sample :
Available | Customized Request
Design Height :
257 MM
Description

GUOMAT Air Shock Absorber 3B10X7 Pneumatic Air Actuator Triple Convoluted

Product Introduction

Air bellows are the ideal choice for applications requiring short stroke, high thrust single acting actuators. Manufactured from fabric reinforced synthetic rubber in one, two or three convolutions according to stroke and model. They incorporate no reciprocating metal parts and so provide virtually frictionless thrust compared with conventional pneumatic cylinders.

Technical Data

Nut / Blind Nut

Top Cover Plate Screw (Nut) Tooth : 2pcs X 3/8-16UNC

Bottom Cover Plate Screw (Nut) Tooth : 1pcs X 3/8-16U

Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : 1/2NPT

Cover Plate

Top Cover Plate Diameter (Width): 131 mm

Bottom Cover Plate Diameter (Width): 131 mm

Material top and bottom plate:Steel

Rubber Bellows

Stroke of Rubber Bellows:257mm

Bumper block / Buffer block

Without Bumper Block

Girdle Hoop / Girdle Ring

With Girdle Hoop :Two Pieces of Girdle Hoop

Triple Convoluted Air Spring Alternative Items

3B12-304 3B12-305 FT 330-29 CI SP2910
3B14-351 3B14-353 FT 430-32 CI SP2895
3B14-354 3B15-375 FT 530-32 CI SP2923
3B15-376 3B15-377 FT 530-35 CI SP2861
3B15-378 FT 960-34 CI SP2863
FT 1330-35 CI SP1539
SP1542
SP1558
SP2141

The Composition Of Industrial Convoluted Air Spring Element Has The Following Aspects

Nut / Blind Nut

As well a permanent part of the Cover Plate assembly. Provides an alternative to bolt installation system. It is inside defect within the iron plate

Gas Hole / Air inlet / Air Fitting

Most usually 1/4 N.P.T. which provides the air entrance to the rubber bellows.

Cover Plate

Curled up to more durable bellows design and the largest quality control in the factory. Allows 100% of the leak test before shipment.

Rubber Bellows

Air Bellows includes four layers of materials: an inner layer, two layer cord - reinforced fabrics, and a cover. Construction of a natural rubber provides - 65F functional properties.

Bumper block / Buffer block

Solid rubber or engineering plastic device designed to prevent major damage to the vehicle or suspension in the event of a sudden loss of air pressure in the spring.

Girdle Hoop / Girdle Ring

Molded wire-wound ring to provide lateral stability of the complex type spring bellows.
