5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer
5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer
5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer
5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer
5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer
5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer
5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer
5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer
Specifications
Brand Name :
Goodyear
Model Number :
1B5-800
Certification :
ISO/TS16949, ISO9001
Place of Origin :
Mexico
MOQ :
5pcs
Price :
USD99.9-299.9/PC
Payment Terms :
L/C, T/T, Western Union Or Others
Supply Ability :
1000PCS/Week
Delivery Time :
3-7 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Brand :
Goodyear
Quality :
100 % Tested
Function :
Reduce Shock
Origin :
Guangzhou, China
After-sales Service :
12 Months
Weight :
0.9KG
M8 :
Max. 25 Nm
Keywords :
Rubber Air Bags
Description

5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer

Product Information

Product No.: Goodyear 1B5-800

Type: Single Convoluted Air Spring

Condition: 100% New

Delivery time: 3 Working Days

Packaging: Strong Netural Box Or As Customers' Request

Shipping way: By sea, By express, By train, etc

Cross Reference

This air spring is imported from Mexico. The goodyear part number is 1B5-800/ 1B5 800/ 1B5800; Bellow number is 579913500/ 579 913 500/ 579-9-13-500/ 579-913-500.

The pneumatic (air) spring is basically a column of confined gas in a container designed to utilize the pressure of the gas as a force medium of the spring. The compressibility of the gas provides the desired elasticity for suspension use. They are highly durable, precisely engineered and cost-effective for use in a wide variety of actuation and vibration isolation applications.

Goodyear 1B5-800 can replace Contitech FS40-6

Goodyear 1B5-800 can replace Contitech FS 40-6

Goodyear 1B5-800 can replace Contitech FS40-6 1/8 M8

Goodyear 1B5-800 can replace Contitech FS 40-6 1/8 M8

OE Number: Volvo AH-0188

Specifications and Detailed Technical Parameters: Goodyear 1B5-800

Top plate

G1/8 AIR FITTING

1.75'' DIA. B.C

3/8'-16 UNC - 2B × 5/8' DEEP TYPICAL OF(2)

Rubber Bellow

5.7' MAX O.D. AT 100 PSIG

3.8' MAX EXTENDED HT.

Bottom plate

1.75' IDA. B.C.

3/8'-16 UNC -2B × 5/8' DEEP TYPICAL OF(2)

Constant Pressure Characteristics

Assembly Height (in) Volume @ 100 PSIG (in3) Nominal Force ( lb)
@ 20 PSIG @40 PSIG @ 60 PSIG @80 PSIG @ 100 PSIG
3.8 51 60 170 280 400 560
3.5 48 130 280 440 620 800
3.0 41 210 420 660 850 1100
2.75 37 240 480 700 1000 1250
2.5 33 260 520 800 1050 1350
2.0 26 280 560 850 1150 1450
1.8 24 280 580 900 1200 1500

The Real Pictures of Goodyear 1B5-800
5.7' Max. OD 1B5 1B5-800 Goodyear Truck Helper Air Bags 579-913-500 Air Spring Buffer
