Material characteristics of heavy castors
1. Wheel material for heavy castors:
Heavy casters are used for the movement of heavy equipment, so the wheels of heavy casters

generally use hard tread single wheels. Such as nylon wheel, cast iron wheel, forged steel wheel,

hard rubber wheel, polyurethane wheel and phenolic resin wheel are ideal choices.
Material characteristics of heavy castors

2. Support for heavy casters:
The support of heavy castor usually adopts metal materials as the main body, including ordinary steel

plate stamping forming, cast steel forming, die forging steel forming, etc., which is usually based on

flat plate assembly. The steel plate thickness of heavy castors generally adopts 8mm, 10mm and

16mm steel plates.

3. Wheel diameter of heavy castors:
According to the principle that the larger the diameter of the wheel, the more flexible the rotation is,

the common specifications include 4-inch casters, 5-inch casters, 6-inch casters, 8-inch casters,

10-inch casters and 12-inch casters, and 16 inch and 18 inch wheels can be used for extra heavy

casters.

4. Rotating plate of heavy universal wheel:
Heavy casters usually use double-layer steel ball runway, stamping forming and heat treatment. For

the rotating plate of the extra heavy universal wheel, the plane ball bearing or plane needle roller

bearing with greater force is generally used, and the cone bearing is matched, which effectively

improves the load capacity of the heavy caster. For the special impact resistant heavy universal

wheel, the rotating plate is made of die forged steel, which effectively avoids the welding of

connecting plate bolts and improves the impact resistance of casters with greater strength.
