Specifications
Model Number :
GBC22s 009G7055
Certification :
UL,CSA
Place of Origin :
China
MOQ :
1pc
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram,Paypal
Supply Ability :
1000pcs per month
Delivery Time :
3-7 working days
Packaging Details :
Carton box
Material :
Brass
Refrigerants :
CFC, HCFC, HFC
Application :
Industrial / Household
Type :
straightway
Temperature of medium :
-40 +150° C
Ambient temperature :
-50 +80° C
Max. Pressure :
46 bar
Permissible working pressure :
PB35 bar
Size :
7/8in 22mm ODF
MWP :
650psig
Description

HVAC Brass shut-off Ball Valve GBC22s 009G7055 for Industrial / Household Usage with access port

GBC ball valves are manually operated shut-off valves suitable for bi-directional flow.

GBC valves are used in liquid, suction and hot gas lines in refrigeration, freezing and air conditioning systems.

GBC valves offer maximum tightness, both externally as well as internally across the seat.
GBC ball valves give maximum flow in the fully open position.

They are designed for operation in all temperature conditions without problems occurring as a result of liquid being trapped internally.

Features
Flow without pressure drop
¼ Turn from fully open to fully closed valve
Rotation stop for fully open and fully closed valve
Arrow on spindle top to indicate valve closed or open
Can be panel mounted
Bi-directional flow, i. E. Valve orientation is unimportant
"Hermetically" sealed welded construction
Patented spindle seal
Valve seat of special teflon
Burst-proof spindle design
The valve design prevents liquids of beeing trapped internally


RefrigerantsCFC, HCFC, HFC
Temperature of medium-40 +150° C
Ambient temperature-50 +80° C
Permissible working pressure PB35 bar
Max. Pressure46 bar
Max. Permissible leakage to atmosphere< 2.8 gram R22/year
Approvals UL, CSA

Ball Valve
Part Number Description
009G5050 VALVE BALL D/FOSS 1/4
009G5051 VALVE BALL D/FOSS 3/8 + ACCESS
009G5052 VALVE BALL 1/2 + ACCESS
009G5053 VALVE BALL 5/8 + ACCESS
009G5054 VALVE BALL 3/4 + ACCESS
009G5055 VALVE BALL 7/8 + ACCESS
009G5056 VALVE BALL 1-1/8 + ACCESS
009G5057 VALVE BALL 1-3/8 + ACCESS
009G5058 VALVE BALL 1-5/8 + ACCESS
009G5059 VALVE BALL D/FOSS 2-1/8 + ACCESS
009G5066 VALVE BALL D/FOSS 2-5/8 + ACCESS

HVAC Brass shut-off Ball Valve GBC22s 009G7055 for Industrial / Household Usage with access port

HVAC Brass shut-off Ball Valve GBC22s 009G7055 for Industrial / Household Usage with access port
