Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Specifications
Model NO. :
HYRO-250lph
Capacity :
10m3 to 50m3/Hr
Untreaed Water :
for Drinking or Irrigation
Flow Rate :
Can Customized
Incoming Water :
Salt Water
Source Water :
Seawater
Transport Package :
Seaworth
Specification :
L1.1 XW1.2XH1.6
Trademark :
JISHUI
Origin :
Guangdong, China
HS Code :
842121
Supply Ability :
500
Shipping Cost :
To be negotiated| Freight Cost Calculator
Certification :
ISO9001, CE
Salt Rejection Rate :
98.0%
Application :
Industry
Samples :
US$ 3000/Piece 1 Piece(Min.Order) |
Description

Product Description

sea water reverse osmosis seawater reverse osmosis salt water desalination swro


Features

Salted water is not always the same. Depending on whether they come from warm or cold oceans, closed or open seas, their salt content will vary. This is a short comparison between samples:

Brackish water:0,5 to 10 g/l, (TDS range: 2000ppm to 20000ppm)
Northern Sea close to estuaries :21 g/l (TDS range: 10000ppm to 21000ppm)
Atlantic Ocean :35 g/l (TDS 35000ppm)
Mediterranean Sea :38 g/l (TDS 38000ppm)
Arabian Sea :45 g/l (TDS45000ppm)
Red sea: 41g/L (TDS 41000ppm)
Dead Sea :300 g/l. (TDS 300,000ppm)

Different Water TDS(Total Dissolved Solids) compare and usage

Raw water/
Application		Bottled water,
Bag water		City tap waterBrackish waterSeawater
TDS Range2-10ppm100-1000ppm2000-20000ppm20000-40000ppm
Direct DrinkingYesYes/NoNoNo
Cooking, human
consumption, washing		YesYesNoNo
Irrigation, Industry,
Animal Drinking		YesYesNoNo




SWRO Process steps introduction

Pre-treatmentFeed water pump, Stainless steel 316LProvide pressure for filters;
Quartz sand filterRemove suspended particle and large impurity. In this system;
Active Carbon Filter (option)Remove the color, free chloride, organic matter, harmful matter, ect;
Anti-scalant systemTo add chemicals to remove some impurities and prolong thememebranes using/washing time(prevent membrane blocking)
Manual/Auto control valvesFlushing sand/carbon filter after some time
5micron filterRemove larger than 5 micro colloids in the water. In this system
1micron filterRemove larger than 1 micro colloids in the water. In this system
Seawater RO Main PartHigh pressure pump, Stainless steel 316LProvide the high pressure to RO membrane;
Ro membranesMore than 98% desalination rate, can remove ions except H2O.
CIP systemTo washing the membranes when it is blocked after using for long time
Electronic control panelPC controller or PLC and HMI controller


SWRO process flow chart:

Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro

Product Parameters
HY-SWRO-500L/hr (10m3/D)
Flow rate10000L/dayRecovery rate 30%
Applicable power 380V/50HZ 3 phaseRated power4 KW
Feedwater TDS<45000ppmfreshwater TDS<600ppm
Working pressure60 baroperating temperature5-45ºC
Feedwater residual chlorine<0.1ppmFeedwater SDI<5
Feedwater turbidity<1NTUFeedwater PH value3-10 NTU
RO membrane housing4040, 4 pieceRO membrane 4 piece
plant specification1.2X1.2X1.65(m)Net weight330Kg
Packing specification(Plywood)1.3X1.3X1.75(cm)Gross weight350Kg

Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro

Related SWRO


Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro

Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro

Certifications

Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro

Company Profile

Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro

Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro

exbition

Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Case

Sea Water Reverse Osmosis Seawater Reverse Osmosis Salt Water Desalination Swro
Buying Guides

In order to make the quote best fit your demand, kindly confirm as below:
1- Untreated water: from well water(send water test report),seawater or other?
2- Treated water purpose: Meet city tap water standard for humandaily use(TDS less than 500ppm) or other purposes?
3- Outpu capacity: How many liters/gallons per hour do you need?
4- Will the power supply 380v/50hz/3ph or others there?
I would like to introduce our company HaiYuan Water Treatment CO.,Limited.
Our advantages:
--We can give you what you the ideal price and quality.
- We are dedicated in water treatment since 2006
- Export experience over 100 countries, familiar with vary water quality.
- Customized water treatment solution for varied industries
- ISO9001 quality certification and CE certification & OEM service available.
Contact Us now get more info.
