AISI 304 Stainless Steel Wire Rope 1*19 For General Purpose Applications
AISI 304 Stainless Steel Wire Rope 1*19 For General Purpose Applications
AISI 304 Stainless Steel Wire Rope 1*19 For General Purpose Applications
AISI 304 Stainless Steel Wire Rope 1*19 For General Purpose Applications
AISI 304 Stainless Steel Wire Rope 1*19 For General Purpose Applications
AISI 304 Stainless Steel Wire Rope 1*19 For General Purpose Applications
Specifications
Brand Name :
Suyang
Model Number :
1*19
Certification :
QUALITY MANAGEMENT SYSTEM CERTIFICATE
Place of Origin :
Jiangsu, China
MOQ :
1000 Meters
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
10 ton/month
Delivery Time :
25-40 days
Packaging Details :
Pallet、Wooden Cases
Material :
304 316
HS Code :
7312100000
Length :
As Required
Tensile Strength :
According To Customer Requirements
Description

AISI 304 Stainless Steel Wire Rope for General Purpose Applications

Descriptions

  1. The multi-purpose stainless steel wire rope is made from high-quality stainless steel, offering excellent resistance to rust, corrosion, and harsh environmental conditions, making it ideal for long-term use in construction and safety applications.

  2. Designed to withstand heavy loads, this wire rope provides superior tensile strength, ensuring reliable performance in demanding tasks such as lifting, rigging, and securing structures.
  3. These stainless steel wire ropes are widely used in construction, mining, and transportation industries. The 19×7 configuration, with its balanced strength and flexibility, is particularly suited for winches, hoists, and cable railings, while the 1×19 and 1×37 ropes are preferred for static applications like guy wires and balustrades.

Technical Specification

Structure Nominal Diameter / MM Minimum Breaking Force / KN Reference Weight (KG/1000M)
AISI 304
06Cr19Ni10
1×19 8 40 320
9.5 56.4 451
10 62.5 500
11 75.7 605
12 90.1 720
14 123 980
16 160 1280
18 203 1620
1×37 12 85 720
14 116 980
16 151 1280
18 191 1620
19.5 224 1901
21 260 2205
22.5 299 2531
24 340 2880
19×7 12 74.2 562
14 101 764
16 132 998
18 167 1264
20 206 1560
22 249 1888
24 297 2246
35W×7 16 128 1075
18 162 1361
20 200 1680
22 242 2033
24 288 2419

Details Photos

AISI 304 Stainless Steel Wire Rope 1*19 For General Purpose ApplicationsAISI 304 Stainless Steel Wire Rope 1*19 For General Purpose ApplicationsAISI 304 Stainless Steel Wire Rope 1*19 For General Purpose ApplicationsAISI 304 Stainless Steel Wire Rope 1*19 For General Purpose Applications

FAQ

Q1: Wonder if you accept small orders?

A1: Do not worry. Feel free to contact us .in order to get more orders and give our clients more convener, we accept small order.
Q2: Can you send products to my country?
A2: Sure, we can. If you do not have your own ship forwarder, we can help you.
Q3: Can you do OEM for me?
A3: We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.
Q4: What's your payment terms ?
A4: By T/T,LC AT SIGHT, 30% deposit in advance, balance 70% before shipment.
Q5: How can I place the order?
A5: First sign the PI, pay deposit,then we will arrange the production.After finished production need you pay balance. Finally we will ship the Goods.
Q6: When can I get the quotation ?
A6: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.
