Milling 5-Axis Cnc Machine For Home
Milling 5-Axis Cnc Machine For Home
Specifications
Brand Name :
GUANGLIJIN
Model Number :
G5-220 Micro Five-Axis Engraving And Milling Machine
Place of Origin :
China
Certification :
CE Certificate
MOQ :
1
Packaging Details :
Fumigation wooden frame - in line with international standards
Delivery Time :
30 days
Payment Terms :
T/T
Supply Ability :
100 units/month
Description

Technical Parameters:

No. Item Details
1 B axis reducer Alpha, Germany Rated torque 44.6n.m,
Instaneous max. torque 156n.m,
Rated speed 43 rpm, max. speed 85 rpm
2 C axis reducer Japan Rated torque 6.4n.m,
Instaneous max. torque 22.3n.m,
Rated speed 300 rpm, max. speed 600 rpm
3 Transmission components Rexroth, Germany Repeatability: +/-0.005mm
4 Operation SYNTEC system 10.4'' touch screen
5 Servo motor 400w/ 200w
6 Spindle electric 2.5kw, max. speed 60000 rpm
water cooling with flow-alarm
7 Tool magazine servo-drive Up to 12 tools
8 Tool holder ISO 10
9 Collet chuck ER-11
10 Lubrication Timing automatic oiling
11 Working flatness +/-0.005mm
12 X axis stroke 220mm
13 Y axis stroke 105mm
14 Z axis stroke 115mm
15 Body weight 0.5 tons
16 Front door single swinging door
17 Layout (mm) main body 620 width*740 depth*1520 height
18 Power requirement 220v/50hz
Milling 5-Axis Cnc Machine For Home

Support and Services:

Technical support
Installation
Training
Maintenance
Troubleshooting
Software upgrade

Packing and Shipping:

Fumigation wooden case by sea or by air

FAQ:

Q: Are you a dealer or manufacturer?
A: We, Guanglijin, is a manufacturer of CAD/CAM CNC machine with over 20 years experience.
Q: Where are you from?
A: We are from Shenzhen China, one of the most creative city in the world.
Q: Do you provide overseas support or service?
A: Yes, we have a technican team which can travel abroad to do global service and support.
Q: Does this machine come with any certification?
A: Our machines are CE certificated.
