DIN 1X16-PLC SC/APC LGX Modulized Splitter Insert Cassette Type Optical PLC Fiber Splitter
DIN 1X16-PLC SC/APC LGX Modulized Splitter Insert Cassette Type Optical PLC Fiber Splitter
Specifications
Brand Name :
HODCY
Model Number :
DIN 1X16-PLC SC/APC
Certification :
CE ROHS
Place of Origin :
CHINA
MOQ :
100PCS
Price :
6.0USD/PCS
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
50000 Pieces per Week
Delivery Time :
3-5 days
Packaging Details :
1PCS: 26*22*4cm ; 50PCS :65*43*38cm/9.38KGS
Product name :
Cassette Type Optical Fiber PLC Splitter
Application :
EPON, GPON, BPON, FTTX, FTTH Network
Connector :
SC/APC,SC/UPC
Fiber Type :
G657A1,G657A2,G652D
Branches :
1x16
Wavelength :
1260 to 1650nm
Cable :
0.9/2.0/3.0 mm
Storage temperature :
- 45~+85℃
Insertion loss :
≤0.1dB
Return loss :
≥55dB
Optical Splitter Type :
DIN/ Cassette Type
Description
The fiber optic splitter is one of the most important passive devices in the optical fiber link. Waveguides are fabricated using lithography onto a silica glass substrate, which allows for routing specific percentages of light. As a result, PLC splitters offer accurate and even splits with minimal loss in an efficient package.
It is an optical fiber tandem device with many input and output terminals, especially applicable to a passive optical network (EPON, GPON, BPON, FTTX, FTTH etc.) to connect the MDF and the terminal equipment and to branch the optical signal.
Main characteristics:
• Main passive PON component
• Wave range 1260nm-1650nm
• Best attenuation rates
• Low insertion loss
• Large directivity
• Low PDL level

Specification

Fiber optic PLC splitter technical specifications
Model name PLCS-109
Wavelength(nm) 1260-1650
Free Sample YES
Material PVC;ABS
Design OEM & ODM
Specifications A (2.4.8 port) : 60L*7W*4H mm
B (16 port ) : 60L*12W*4H mm
C (32 port ) : 80L*20W*6H mm
Connectors FC, SC, ST , LC, LC/APC, SC/APC, MU and FC/APC
fiber optic connectors are available
Parameters 1x2 1x4 1x8 1x16 1x32 1x64 1x128
Insertion Loss (dB) ≤4.2 ≤7.4 ≤10.7 ≤13.9 ≤17.2 ≤21.5 ≤24
PDL (dB) ≤0.2 ≤0.2 ≤0.3 ≤0.3 ≤0.3 ≤0.4 ≤0.5
Uniformity (dB) ≤0.6 ≤0.8 ≤0.8 ≤1.0 ≤1.5 ≤2.0 ≤2.0
Return Loss (dB) ≥50
Directivity (dB) ≥55
Temperature Range (°C) -40~+75
Storage Temperature (°C) -40~+85
NOTE: The above parameter is for splitter with connector, if w/o connector, insertion loss will reduce by 0.2dB.


Application

1)Optical Signal Distribution
2)Data Communications
3)Lan and CATV System
4)FTTX Deployment
5)FTTH Network
6)Passive Optical Networks (PON)
7)Measuring System and Laser System
8)DWDM and CWDM Systems
