4 Wire smoke detector with signal output
4 Wire smoke detector with signal output
Specifications
Brand Name :
SUPERSAFE
Model Number :
SS2188-YG
Certification :
CE
Place of Origin :
CN
MOQ :
50pcs
Payment Terms :
T/T, Western Union
Supply Ability :
500,000pcs
Power :
DC12 -24 V
Dimension :
104*51mm
Alarm output :
Relay output N. C
Description

Smoke Detector With Network Signal Output



Products Feature:

The detector works once connected to DC power directly. Operation indicator flashing signifies detectors working normally and alarming indicator on signifies detector alarming. Built-in a couple of outpot contact, which keep close when work normally and disconect after alarm. Auto-reset when no smoke existing nearby, installing with mounting base.


. INFRARED PHOTOELECTRONICS SENSOR

. AUTO RESET

. INTELLIGENT LOGIC CONTROL

. NETWORK OUTPUT /LED INDICATING ALARM

. ANTI-LIGHT, MOTHPROOF, DUSTPROOF

. STRONG ANAPTABILITY FOR CIRCUMSTANCE

. SMT DESIGN, HIGH STABILITY.


Technical specification:

Operation voltage: DC12 -24 V

Static current: Less than 2mA

Alarm current: Less than 10mA

Alarm indication: Red LED on

Operating humidity: Less than 95%RH

Anti-RFI: 10MHz-1GHz 20V/m

Detecting area: 80 square meter(with the installation height of 6m-12m), and 60m square meter(with the installation height less than 6m)

Alarm output: Relay output N. C., DC28V, 100mA

Dimension size: 104*51mm

Sensitivity: I Level
