V-scored PCB depaneling machine, PCB depaneler
V-scored PCB depaneling machine, PCB depaneler
Specifications
Place of Origin :
China
Brand Name :
Juanxin
Model Number :
YS-805A
Price :
USD1.00
Packaging Details :
Carton Box or Wooden Case
Delivery Time :
3-5 days
Payment Terms :
TT
Supply Ability :
300-500SETs/month
MOQ :
1SET
Certification :
CE
Name :
V-scored PCB depaneling machine, PCB depaneler
Usage :
Cut v-scored pcb to units
PCB length :
Max 400mm
Description

V-scored PCB depaneling machine, PCB depaneler

Usage

The machine is used to v-cut pcb board to small pcb.

According to the length of your pcb, we have different models for you. Such as YS-805 for pcb less than 400mm length, and YS-830 for any length pcb cutting.

Available PCB thickness: from 0.2mm to 3.2 mm

Available V-cut thickness: from 0.2mm to 2.0mm

If you are interested in our machine, please tell us the length of your pcb, we will recommend a suitable machine for you.

Features

1, Controlled by microcomputer program, it can cut board accurately with no error.

2, Adjustable blade moving speed: 300mm/s or 500mm/s. As per customers' need, certain speed can be set.

3, Upper blade can be adjustable between 0 and 2mm to meet different thickness of PCB and V-cut.

4, Operation platform can be adjustable higher and lower between 0 and 50mm.

5, As per your pcb length, we have different models for you. So any length pcb is available.

6. Available board thickness: 0-3.2mm, V-groove thickness:0-2mm

7. Pre-set the cutting start and end point to well control the cutting length.

8. The blades are sharp and endurable. And they can be sharpened between 7 and 10 times.

9. Minimize the shearing stress to avoid micro-cracks of the solder joints

Parameters

Model: YS-805A

Cutting Length:0-400mm

Outer dimension:L740xW550XH460mm

PCb length: Different models for different length of pcb cutting

Electric Load:AC220V 50Hz & AC110V/60HZ

Electric Power:250W

Suitable for:V-Groove PCB Board/Aluminum PCB

Package:Wooden Case

Weight:Approx.60KG
