Specifications
Brand Name :
Sibo
Model Number :
Q101T
Certification :
CE RoHS
Place of Origin :
China
MOQ :
one piece
Payment Terms :
PayPal,Bank Wire,Western Union etc.
Supply Ability :
over 3000 units each month
Delivery Time :
7 days for sample order,25 days for batch order
Packaging Details :
neutral packaging or custom
Interface :
DC IN/USB/RJ45
Power Supply :
DC IN (9 - 24 V)
Display :
10 Inch IPS Display, Resolution:1280 x 800, Brightness: 350 cd/m2
Feature :
Microphone,Speakers,Camera, Wifi&Bluetooth
CPU :
Rockchip RK3566,Cortex A55,Quad-Core, 1.8Ghz
RAM :
4GB
Nand Flash :
32GB
Option :
Relay/GPIO/IR/RS485/RS232
Keyword :
10 Inch android POE Touch Tablet
Description

White Color 10 inch Android Wall Mount Touch Tablet RJ45 Power Over Ethernet with LED Light bar Temperature Sensor Multi ports

This white color 10.1 inch wall mountable touch screen can be perfectly suitable for home automation,building control requirement or applications.

The hottest POE function standard IEEE802.3at,POE+,class 4,25.5W option,only one ethernet cable can be provided both power and data to this slim 10" android OS rooted control panel.

Other accessories can be also available LED Light bar and Relay/GPIO/IR/RS485/RS232 etc multi ports.

Advantages:

  • Android 13 OS,built in Google Play Store
  • POE Ethernet RJ45 port ( IEEE 802.3 af 48V standard POE) or DC IN 9-24V
  • On wall surface
  • adjustable RGB LED light indicator,will provide the demo apk and source code
  • free to provide the customized splash screen with your company logo

Back Interface:

  • DC IN (9-24V)

  • RJ45

  • USB-C

Network:

  • 802.11a/b/g/n/ac/ax(WiFi 6E)
  • LAN Ethernet RJ45 port
  • Bluetooth 5.3

White Color 10 inch Android Wall Mount Touch Tablet RJ45 Power Over Ethernet with LED Light bar Temperature Sensor Multi portsWhite Color 10 inch Android Wall Mount Touch Tablet RJ45 Power Over Ethernet with LED Light bar Temperature Sensor Multi portsWhite Color 10 inch Android Wall Mount Touch Tablet RJ45 Power Over Ethernet with LED Light bar Temperature Sensor Multi portsWhite Color 10 inch Android Wall Mount Touch Tablet RJ45 Power Over Ethernet with LED Light bar Temperature Sensor Multi portsWhite Color 10 inch Android Wall Mount Touch Tablet RJ45 Power Over Ethernet with LED Light bar Temperature Sensor Multi portsWhite Color 10 inch Android Wall Mount Touch Tablet RJ45 Power Over Ethernet with LED Light bar Temperature Sensor Multi ports

White Color 10 inch Android Wall Mount Touch Tablet RJ45 Power Over Ethernet with LED Light bar Temperature Sensor Multi ports

CPU RK3566 Quad core cortex A55
RAM 4GB
Internal memory 32GB
Operation system Android 13
Touch screen 10-Point capacitive touch
Panel 10.1 "high-definition full view screen fully bonded
Resolution 1280*800
Display mode Normally black
Viewing angle 85/85/85/85(L/R/U/D)
Contrast ratio 800
Luminance 250cd/m2
Aspect Ratio 0.673611111
WiFi 802.11a/b/g/n/ac/ax(WiFi 6E),802.15.4/Thread
Buletooth Bluetooth 5.3
Ethernet 100M/1000M ethernet

Type-C USB2.0 supports OTG functionality
Relay port Control home devices that support Relay connections
RS-232 Serial port Communicating with RS232 devices
IR port Used for infrared remote control, with an external plug-in receiver, which can control the device
Zigbee 3 Optional
I/O port Input (output) ports between equipment and external devices
RJ45 Ethernet interface ( POE function standard IEEE802.3at,POE+,class 4, 25.5W )
Power jack DC power input
Video format MPEG-1,MPEG-2,MPEG-4,H.265,H.264,VC-1,VP8,VP9, etc.
Audio format MP3/WMA/AAC etc.
Photo jpeg
Microphone Four microphones
Speaker 2*2W BOX chamber horn
LED light strip RGB
Temperature and humidity sensor YES
Camera 5MP from a conventional perspective
Working temp 0--40degree
Language Multi-language
Usage Wall hanging (with accessories), placement (with base)
Adapter Adapter,12V/1.5A
User manual yes







Q:Are you manufacturer?
Yes, we are manufacturers.We can provide OEM / ODM customized service according to our customers’ various application and demands.


Q: What is the minimum order?
We accept one piece for standard products. If require OEM, will see detailed requirements and confirm MOQ to you from our sales department.

Q: Can we get the free sample?
Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation.

Q: What's Your MOQ?

To support customer, ERhino Industrial PDAs devices/rugged phones MOQ quantity will be 1 piece,we can even customized with your logo if needed.

Q: Can i choose multiple function into 1 device?

A: Yes, you can choose multiple fuction into one rugged tablet, optional functions:NFC,RS232/RS485/GPIO,LED Light etc.

Q: How to order and pay?

A: We accept T/T (bank transfer), Western Union,Paypal etc.

Q: What's Your Products Warranty?

A: We Offer 12 Months Warranty after shipment sent.

Q: How long it will take for delivery?

A: For production lead time around 3-10days depend on requirement, and shipping time by DHL/UPS/FEDEX/TNT, delivery time would around 3-5 working days. For some remote place, delivery time maybe a little bit longer.

Q:How to repair the device if any problem ?

A: We will provide technical support online to solve problem; If for the hardware problem , we couldsend the parts or components and teach customer to fit if they have technician or can also send backto us to fix it.

Q: Can you do customized and preload our software?

Yes, with many years electronic products manufacturing experience, we can support customized order for you.
